ABB System Pro M Compact S200 Miniature Circuit Breaker 2-Pole 15A Type K 400V AC 6 kA Breaking Capacity 2CDS252001R0457
Specifications
| Country of Origin | Germany |
|---|---|
| Range | System Pro M Compact |
| Brand | ABB |
| Height | 88mm |
| Model | 2CDS252001R0457 |
| Depth | 69mm |
| IP Rating | IP20, IP40 |
| Width | 35mm |
| Mount Type | DIN Rail |
| Current Rating | 15A |
| Series | S200 |
| Terminal type | Screw |
| Breaking Capacity | 6kA |
| Number of Poles | 2 |
| Standards/Approvals | IEC/EN 60947-2, IEC/EN 60898-1 |
| Rated AC Voltage | 400V ac |
| Tripping Characteristics | Type K |
| Better World Claim | Designed for Disassembly |
| Tripping Mechanism | Thermomagnetic, Electromagnetic |
Key Features
- Rated current of 15A suitable for moderate inrush current applications.
- Type K tripping characteristic designed for motor control circuits and commercial distribution.
- 6 kA breaking capacity limits fault energy effectively.
- Thermomagnetic and electromagnetic dual protection mechanism.
- Compact 35mm width saves panel space on DIN rail installations.
- Visual red/green indication for contact status.
- Screw terminals ensure secure electrical connections.
- Operates up to 400V AC with compatibility for 35x15mm and 35x7.5mm DIN rails.
Product Description
ABB 2CDS252001R0457 System Pro M Compact S200 Miniature Circuit Breaker is a 2-pole device rated at 15 amperes, supporting operation at up to 400V AC with a breaking capacity of 6 kA. It combines thermomagnetic and electromagnetic tripping mechanisms, providing both overload and short-circuit protection suitable for industrial, commercial, and residential electrical applications.
Designed for DIN-rail mounting, this compact breaker measures 35mm in width, 88mm in height, and 69mm in depth, enabling efficient use of panel space. The screw terminal type provides reliable conductor connections, while the unit’s IP20 and IP40 ratings ensure protection against ingress in typical electrical environments.
The Type K tripping characteristic makes it ideal for motor control circuits that experience moderate starting currents. Visual red/green indicators clearly show the contact status for quick operational checks. It is compatible with standard TH35 DIN rails, including 35x15mm and 35x7.5mm sizes, allowing flexible installation.
Engineered to perform in ambient temperatures ranging from −25 °C to +55 °C and designed for pollution degree 3 environments, this breaker withstands rigorous industrial conditions. Auxiliary accessories like shunt trips and undervoltage releases can be added to expand its functionality.
Rated current of 15A ensures consistent circuit protection. Type K characteristic suitable for applications with moderate inrush currents. 6 kA breaking capacity limits fault energy effectively. Thermomagnetic and electromagnetic dual-mode protection.
Compact size saves panel space with 35mm width. Screw terminals offer secure and reliable connections. Visual red/green indication for on/off status. Mounts on DIN rails compatible with 35x15mm and 35x7.5mm. Rated for operation between −25 °C to +55 °C ambient temperature.
Designed for pollution degree 3 environments applicable to industrial use.
This Miniature Circuit Breaker is commonly used in industrial control panels, commercial distribution boards, motor control circuits, and general-purpose feeder protection. It ensures reliable interruption of overcurrents while maintaining durability under demanding electrical installation conditions.
Explore our range of ABB and System Pro M products at EnvMart for dependable electrical protection solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has a rated current of 15A, making it suitable for moderate inrush current applications.
It features a breaking capacity of 6 kA, effectively limiting fault energy during overcurrent conditions.
The dimensions of this unit are 35mm in width, 88mm in height, and 69mm in depth.
It operates at a maximum rated AC voltage of 400V.
This model is designed for DIN rail mounting and is compatible with 35x15mm and 35x7.5mm DIN rails.
It has a Type K tripping characteristic, which is designed for motor control circuits that experience moderate starting currents.
It combines thermomagnetic and electromagnetic tripping mechanisms to provide both overload and short-circuit protection.
The unit has an IP rating of IP20 and IP40, providing protection against ingress in typical electrical environments.
It can operate within an ambient temperature range of −25 °C to +55 °C.
This model has screw terminals, ensuring secure and reliable electrical connections.
It complies with IEC/EN 60947-2 and IEC/EN 60898-1 standards.
It is commonly used in industrial control panels, commercial distribution boards, and general-purpose feeder protection.
