STMicroelectronics 2-Channel General Purpose Comparator Open Collector TTL Output 5-15 V 14-Pin SOIC LM219DT

STMicroelectronics LM219DT is a 2-channel general purpose comparator designed for electronic applications requiring precise and reliable signal comparison. It offers an open collector TTL output type enabling easy interfacing with digital logic circuits. The built-in fast response time of 80 ns ensures suitability for high-speed circuit requirements.

This comparator operates within a supply voltage range of 5 V to 15 V, making it versatile for various power configurations. Packaged in a space-efficient 14-pin SOIC surface mount package, it supports modern high-density PCB layouts. The device dimensions are 8.75 mm in length, 4 mm in width, and 1.65 mm in height, allowing compact integration in electronic assemblies.

Designed for robustness, the LM219DT can reliably function over a wide temperature range from -45°C to 105°C, suitable for industrial and automotive working conditions though it is not certified as automotive grade. Its typical supply current of 11.5 mA enables low power operation while maintaining performance.

The two channels integrated within the package allow for multiple comparator tasks within a single component, simplifying design complexity and reducing PCB space requirements. Open collector TTL output is ideal for interfacing with various logic standards and allows wired-AND connection capability.

Applications for the LM219DT comparator include waveform shaping, voltage level detection, threshold detection, and signal conditioning in industrial, laboratory, and consumer electronics environments. This device is widely used in power supplies, data acquisition systems, and control circuits.

Typical response time of 80 ns for fast switching. Supports supply voltages from 5 to 15 volts. Compact 14-pin SOIC surface mount package. Operating temperature range of -45°C to 105°C. Low supply current of 11.5 mA for efficient power use.

Two independent comparator channels integrated. Open collector output compatible with TTL logic standards. Precisely dimensioned for space-saving PCB designs. Explore more quality semiconductor Comparators and amplifiers on EnvMart to enhance your electronic designs.
