Bourns Non-Resettable Fuse 750mA 125V AC Ceramic Body High Inrush SF-2410HI075T-2

Bourns SF-2410HI075T-2 Non-Resettable Fuse is a single blow fuse designed for overcurrent protection in electronic circuitry operating at 125V AC and 750mA current rating. Featuring a ceramic tube body with high inrush current characteristics, it provides robust performance in demanding electrical applications.

The fuse is housed in a surface mount reel package suitable for automated assembly. It offers a 300A breaking capacity, enabling safe interruption of fault currents and protecting sensitive electronics. The compact size with dimensions of 2.6mm width, 2.6mm height, and 6.1mm depth supports space-constrained designs.

Rated for operating temperatures ranging from -55°C up to 125°C, this fuse is halogen-free and RoHS compliant, aligning with environmental and safety standards. Its resistance is specified at 166.6mΩ, ensuring predictable electrical characteristics within the SF-2410HI-T series.

Common applications include protection for notebooks, LCD monitors and backlight inverters, Power-over-Ethernet (PoE) and PoE+ systems, PC servers, power supplies, battery protection systems, and white goods. The fuse helps safeguard devices from damaging electrical faults during operation.

Single blow fuse designed for high inrush current applications. Ceramic tube body provides durability and heat resistance. Surface mount packaging suitable for automated assembly processes. Breaking capacity of 300A ensures effective circuit interruption.

Operating temperature range from -55°C to 125°C for versatile use. Halogen-free material compliant with RoHS standards. Compact dimensions of 2.6mm width, 2.6mm height, and 6.1mm depth. Series SF-2410HI-T offers reliable electrical performance with 166.6mΩ resistance.

Applications include notebooks, LCD monitors, power supplies, and battery protection. Manufactured in Taiwan, Province of China, ensuring quality and compliance.

This fuse is ideal for industrial, commercial, and consumer electronic uses requiring reliable circuit protection. Browse the Electronics & Electricals category at EnvMart for a comprehensive range of fuses and circuit protection components.
