KEMET SPST Through Hole Reed Switch 300 mA 110 V ac/dc OHD3-125B

KEMET OHD3-125B SPST Through Hole Reed Switch is designed for reliable switching with a maximum current rating of 300 mA and a maximum switching voltage of 110 V ac/dc. This switch utilizes a durable nickel iron alloy contact material combined with a tab leads terminal type for seamless through hole mounting on printed circuit boards.

The switch’s compact size, measuring 27 mm in length, 13.5 mm in width, and 12.5 mm in depth, allows easy integration into various electronic assemblies. Its robust operating temperature range from -20°C to 150°C accommodates demanding industrial, automation, and consumer electronics environments.

This product is manufactured in Japan and meets international standards UL, CSA, RoHS, and TUV, ensuring safety and environmental compliance. The reliable low contact resistance of 150 mΩ optimizes electrical performance, minimizing signal loss.

Typical applications include signal switching in industrial controls, automation systems, HVAC controllers, motors, and other electrical appliances requiring dependable on/off operations. The through hole mounting and tab leads facilitate straightforward assembly and soldering onto PCBs.

Contact configuration: SPST for single pole single throw switching. Maximum switching current: 300 mA. Maximum switching voltage: 110 V ac/dc. Maximum switching power: 6 W. Contact resistance: 150 mΩ for efficient conduction.

Durable nickel iron alloy contacts. Terminal type: Tab leads. Mounting type: Through hole. Operating temperature range: -20°C to 150°C. Compact dimensions of 27x13.5x12.5 mm. Compliance with UL, CSA, RoHS, and TUV standards.

This switch is ideal for applications in electrical, industrial automation, consumer electronics, and HVAC sectors. Explore more options in our Reed Switch category for comprehensive solutions suited to your design and operational needs at EnvMart.
