KEMET SPST Through Hole Reed Switch 270 mA 264 V ac TRS5-50BLRVU

KEMET TRS5-50BLRVU SPST Through Hole Reed Switch is designed for reliable on/off operations with quick response time and extended operational life. It is engineered with nickel iron alloy contacts, ensuring high durability and superb environmental resistance.

This reed switch can handle a maximum switching current of 270 mA, voltage up to 264 V AC, and power of 60.5 W, making it suitable for a wide range of electronic switching applications. Its low contact resistance of 150 mΩ enhances signal integrity.

With through-hole mount terminal types and cable terminals, installation is straightforward and secure. The device functions effectively within a temperature range of -20°C to 130°C, providing excellent temperature accuracy of ±2.5°C.

Applications include temperature detection, overheat monitoring in electric appliances, heater control for rice cookers, defrost control for air conditioners and vending machines, roll heater management in copying machines, and radiator water temperature detection for automotive electric fan control.

Supports a maximum switching current of 270 mA. Operates up to 264 V AC with a maximum switching power of 60.5 W. Nickel iron alloy contacts provide long-lasting durability. Low contact resistance of 150 mΩ for efficient current flow.

Through-hole mounting with cable terminal type for secure installation. Wide operating temperature range from -20°C to 130°C. Compact dimensions: 8.2 mm (width) x 5 mm (length) x 20 mm (depth). Certified to UL, RoHS, CSA, and REACH standards for safety.

Manufactured in Japan ensuring quality and reliability. This Reed Switch is ideal for industrial, consumer electronics, and automotive applications requiring precise and dependable switching. Explore the Electronics & Electricals category for more high-quality switches and related components on EnvMart.
