KEMET SPST Through Hole Reed Switch 300 mA 110 V ac/dc OHD3-55M

KEMET OHD3-55M SPST Through Hole Reed Switch is designed for precise switching applications requiring up to 300 mA current and 110 V ac/dc voltage. This reed switch features a single pole single throw contact configuration with nickel iron alloy contacts providing high reliability and low contact resistance.

The device has a maximum switching power of 6 watts, making it suitable for a range of electrical and electronic circuits that require reliable on/off control. The switch is mounted through hole with tab lead terminals facilitating easy integration into printed circuit boards.

Its operating temperature range extends from -20°C to 150°C, allowing for use in diverse and demanding industrial environments. The compact size of 27 mm length, 13.5 mm width, and 12.5 mm depth ensures space-efficient installations.

The OHD series includes features like excellent environmental durability and compliance with RoHS standards, emphasizing safe and sustainable production practices. Single pole single throw (SPST) contact design for reliable switching operations.

Maximum switching current of 300 mA and voltage of 110 V ac/dc. Low contact resistance of 150 milliohms for efficient electrical conductivity. Nickel iron alloy contacts provide corrosion resistance and long operational life.

Through hole mounting with tab lead terminals enables robust PCB assembly. Wide operating temperature tolerance ranging from -20°C to 150°C. Compact dimensions to suit space-restricted applications. RoHS compliant ensuring adherence to environmental safety standards.

Typical industrial, laboratory, and manufacturing applications include temperature sensing circuits, power transistor overheating detection, motor control, and general appliance switching. Its thermal guard technology features a temperature-sensitive soft ferromagnetic material that enhances performance reliability under varying thermal conditions.
