KEMET SPST Through Hole Reed Switch 300 mA 110 V ac/dc OHD1-60B

KEMET OHD1-60B SPST Through Hole Reed Switch is designed for precise switching in electrical and automation applications. Operating at a maximum switching current of 300 mA and voltage up to 110 V ac/dc, it delivers reliable performance for various low power circuits.

The switch features a single-pole, single-throw (SPST) contact configuration providing a straightforward on/off operation mechanism. Its nickel iron alloy contacts ensure durable electrical connectivity and minimal contact resistance of 150 milliohms, enhancing signal integrity.

Compact and lightweight, the device measures 18 mm in length, 5.5 mm in width, and 5.6 mm in depth, optimized for through-hole mounting using wire terminals. This form factor facilitates seamless integration into printed circuit boards and other electrical assemblies. It withstands harsh environments with an operating temperature span from -20°C up to 150°C, making it suitable for industrial, laboratory, and commercial electronics applications.

The OHD series reed switch technology incorporates a unique thermal guard known as Thermorite®, a temperature-sensitive ferromagnetic material that changes its magnetic flux density with temperature, contributing to enhanced operational safety and life span. This ensures fast, high-reliability switching with excellent environmental durability.

Compliance with rigorous standards, including UL, RoHS, TUV, and CSA, affirms the device’s quality and environmental safety credentials. Manufactured in Japan, it reflects precision engineering and superior manufacturing standards.

Typical uses include atmospheric temperature detection, overheating monitoring of power transistors and modules, room heaters, motors, hard disk drives, floppy disk drives, and other general appliances requiring robust and reliable switching elements.

SPST contact configuration ensures reliable switching performance. Maximum switching current of 300 mA suitable for low power applications. Rated for maximum switching power of 6 W to handle various load conditions. Compact dimensions: length 18 mm, width 5.5 mm, depth 5.6 mm for easy PCB integration.

Constructed with nickel iron alloy contact material for durability. Wire terminal type designed for through-hole mounting. Operating temperature range from -20°C to 150°C supports wide environmental conditions. Complies with UL, RoHS, TUV, and CSA standards for assured quality.

Manufactured in Japan ensuring excellent product reliability. Explore more high-quality Reed Switches and electrical components in the Electronics & Electricals category at EnvMart.
