Bourns Non-Resettable Fuse Fast Acting Ceramic Body 15A 250V ac SF-3812F1500T-2
Specifications
| Country of Origin | Taiwan |
|---|---|
| Voltage | 250V ac |
| Brand | Bourns |
| Body Material | Ceramic |
| Height | 3.1mm |
| Model | SF-3812F1500T-2 |
| Depth | 10.1mm |
| Width | 3.1mm |
| Current Rating | 15A |
| Series | SF-3812F-T |
| Maximum Operating Temperature | -55°C |
| Resistance | 5mΩ |
| Package Type | Reel |
| Minimum Operating Temperature | 125°C |
| Package Size | 3812 |
| Breaking Capacity | 300A |
| Standards/Approvals | RoHS, UL 248-14 |
| Fuse Characteristics | Fast Acting |
Key Features
- Designed for single blow overcurrent protection.
- Ceramic tube provides durability and heat resistance.
- Fast acting fuse characteristics ensure quick response to faults.
- Surface mount packaging supports automated assembly processes.
- Halogen free construction for safer environmental compliance.
- Breaking capacity up to 300 amperes for high fault current handling.
- Compact size measuring 3.1mm width, 3.1mm height, and 10.1mm depth.
- Operating temperature range from -55°C to 125°C.
Product Description
Bourns SF-3812F1500T-2 is a high-quality non-resettable fuse designed for reliable overcurrent protection in electrical and electronic circuits. Featuring a ceramic body and fast acting fuse characteristics, this fuse ensures rapid interruption during fault conditions to safeguard sensitive components and systems.
This fuse supports a current rating of 15 amperes at an operating voltage of 250 volts AC. Its compact dimensions - 3.1mm width, 3.1mm height, and 10.1mm depth - allow it to be used in densely packed circuit designs. The ceramic construction provides excellent thermal stability, enabling operation over a wide temperature range, from -55°C to 125°C.
The SF-3812F1500T-2 model is surface mount packaged on reels, catering to automated PCB assembly lines, improving manufacturing efficiency. It is halogen free, meeting environmental safety standards and reducing toxic emissions during disposal.
The fuse delivers a breaking capacity of 300 amperes, making it suitable for circuits where high fault currents may occur. Featuring a low resistance of 5 milliohms, it minimizes power loss and ensures effective circuit protection while maintaining circuit integrity.
Single blow fuse provides effective overcurrent protection. Ceramic tube design enhances durability and heat resistance. Fast acting characteristic ensures quick fault interruption. Surface mount packaging compatible with automated manufacturing.
Halogen free materials for environmentally conscious applications. High breaking capacity of 300A for demanding circuits. Compact size supports space-saving circuit layouts. Wide operating temperature range from -55°C to 125°C.
Low resistance of 5 milliohms for minimal voltage drop.
This Bourns fuse is ideal for industrial, electrical automation, and consumer electronics applications requiring robust circuit protection. It complies with RoHS and UL 248-14 standards, ensuring quality and regulatory compliance. Package size is 3812, within the SF-3812F-T series, made in Taiwan, Province Of China.
Explore the full range of Non-Resettable Fuses for varied current ratings and applications within the Electronics & Electricals category at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has a current rating of 15 amperes.
It has a breaking capacity of 300 amperes, suitable for high fault current handling.
The fuse measures 3.1mm in width, 3.1mm in height, and 10.1mm in depth.
The operating temperature range is from -55°C to 125°C.
The fuse features a ceramic body, which provides durability and heat resistance.
It is packaged in a reel format, which supports automated assembly processes.
This model complies with RoHS and UL 248-14 standards, ensuring regulatory compliance.
It has a low resistance of 5 milliohms, which minimizes power loss.
The fast acting characteristics ensure rapid interruption during fault conditions, protecting sensitive components.
This fuse is suitable for industrial, electrical automation, and consumer electronics applications requiring robust circuit protection.
The package size is 3812, which is part of the SF-3812F-T series.
This fuse is manufactured in Taiwan, Province Of China.
