ABB Miniature Circuit Breaker 1-Pole 16A Type C 230V AC 6 kA Breaking Capacity SN201

ABB SN201 Miniature Circuit Breaker, model SN201, is a high-quality 1-pole circuit breaker designed for 16A current rating with a Type C tripping characteristic. It operates efficiently at a rated 230V AC voltage and offers a breaking capacity of 6 kA, making it ideal for residential, commercial, and industrial electrical protection.

The compact design includes dimensions of 18mm width, 85mm height, and 85mm depth, allowing easy installation on standard DIN rails. The device features screw terminal connections, providing secure wiring and reliable operation even in demanding electrical environments. The toggle switch actuator enables straightforward resetting after a trip event for convenience and safety.

Engineered to comply with IEC/EN 60898-1 standards, this MCB ensures exceptional protection against short circuits and overloads. Its Type C tripping characteristic is especially suited for circuits with inductive loads such as motors, transformers, or HVAC equipment, capable of handling inrush currents without nuisance tripping.

The breaker’s IP20 protection rating safeguards the internal components from solid foreign objects while allowing ease of access for installation and maintenance. It is widely used in lighting circuits, motor protection, control panels, and general electrical distribution boards in both commercial and industrial settings.

Compact and DIN rail mountable for efficient electrical panel design. Provides robust short circuit and overload protection with Type C characteristic. Screw terminal type ensures safe and durable electrical connections.

Toggle switch for quick reset and operational ease. Compliant with international safety standards IEC/EN 60898-1. Rated for 230V AC and 16A current, suitable for various applications. Breaking capacity of 6 kA ensures high fault tolerance.

IP20 rated for basic protection against solid objects and limited touch access.

This ABB SN201 series miniature circuit breaker represents a reliable solution for electrical safety in residential, commercial, and light industrial applications. Its versatile design and high-quality standards support stable operation under varying load conditions, facilitating system protection and maintenance efficiency.
