ABB Miniature Circuit Breaker 1-Pole 20A Type D 230V AC 6 kA Breaking Capacity SN201
Specifications
| Country of Origin | India |
|---|---|
| Range | SN201 |
| Brand | ABB |
| Height | 85mm |
| Model | SN201 |
| Depth | 85mm |
| IP Rating | IP20 |
| Width | 18mm |
| Mount Type | DIN Rail |
| Current Rating | 20A |
| Series | SN201 |
| Terminal type | Screw |
| Breaking Capacity | 6kA |
| Number of Poles | 1 |
| Standards/Approvals | IEC/EN 60898-1 |
| Rated AC Voltage | 230V ac |
| Tripping Characteristics | Type D |
| Reset Actuator Type | Toggle Switch |
Key Features
- Designed for effective short circuit and overload protection.
- Type D tripping suitable for high inrush current applications.
- Compact DIN rail mountable design simplifies installation.
- Screw terminal connections ensure secure wiring.
- Toggle switch allows easy manual reset after tripping.
- Breaking capacity rated at 6 kA for safety under fault conditions.
- IP20 rated for protection against accidental contact.
- Complies with IEC/EN 60898-1 standards for circuit breakers.
Product Description
ABB SN201 Miniature Circuit Breaker, model SN201, is a 1-pole, 20A protection device operating at 230 volts AC. It is designed for residential, commercial, and industrial electrical systems requiring reliable short circuit and overload protection.
This circuit breaker features a Type D tripping characteristic, making it ideal for handling high inrush currents common in inductive loads such as motors and transformers. The device supports a breaking capacity of 6 kiloamperes, ensuring safe interruption during fault conditions.
Its compact size with an 18 mm width and DIN rail mounting facilitates easy installation in control panels, distribution boards, and automation systems. The screw terminal type provides secure and stable electrical connections, and the toggle switch offers a straightforward manual reset mechanism for user convenience.
Rated IP20 for protection against accidental contact, this MCB conforms to IEC/EN 60898-1 safety standards, assuring reliability and compliance within electrical installations. Designed for effective short circuit and overload protection.
Type D tripping suitable for high inrush current applications. Compact DIN rail mountable design simplifies installation. Screw terminal connections ensure secure wiring. Toggle switch allows easy manual reset after tripping.
Breaking capacity rated at 6 kA for safety under fault conditions. IP20 rated for protection against accidental contact. Complies with IEC/EN 60898-1 standards for circuit breakers.
This Miniature Circuit Breaker is widely used in industrial automation, machinery control panels, power distribution boards, and both residential and commercial electrical systems requiring robust and safe overcurrent protection.
Explore more circuit protection solutions in the Electronics & Electricals category at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The breaking capacity of this model is rated at 6 kA, ensuring safe interruption during fault conditions.
This circuit breaker has a current rating of 20A, suitable for various electrical applications.
It features a compact DIN rail mountable design, facilitating easy installation in control panels and distribution boards.
The IP rating is IP20, which provides protection against accidental contact.
The dimensions are 85mm in height, 85mm in depth, and 18mm in width.
It has a Type D tripping characteristic, making it suitable for high inrush current applications.
This model uses screw terminal connections, ensuring secure and stable wiring.
It complies with IEC/EN 60898-1 standards for circuit breakers, ensuring reliability in electrical installations.
It features a toggle switch that allows for easy manual reset after tripping.
This miniature circuit breaker is widely used in residential, commercial, and industrial electrical systems for short circuit and overload protection.
The rated AC voltage for the SN201 is 230V AC, making it suitable for standard electrical systems.
The country of origin for this product is India.
