Eaton 700A Centred Tag Fuse NH2 Fast Acting Dual Indication 690V AC Bussmann Series 170M5813D
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 690V ac |
| Brand | Eaton |
| Height | 68mm |
| Length | 72mm |
| Model | 170M5813D |
| Width | 54mm |
| Overall Length | 150mm |
| Current Rating | 700A |
| Series | Bussmann |
| Fuse Type | HSDI |
| Standards/Approvals | UL, CE, IEC, CSA |
| Fuse Characteristics | Fast Acting, Dual Indication |
| Fuse Size | NH2 |
| Tag Width | 25mm |
| Application Category | aR |
| Tag Type | Blade |
Key Features
- Provides fast, reliable protection for thyristors and diodes in electrical equipment.
- Features silver-plated brass contact blades for excellent conductivity and corrosion resistance.
- Compact dimensions of 72mm length, 54mm width, and 68mm height allow installation in confined spaces.
- Rated for 700A current and 690V AC voltage for high-power industrial applications.
- 200kA breaking capacity prevents arcing and burning during high current surges.
- Low power loss of 43W increases energy efficiency during operation.
- Blade type tag with a 25mm tag width featuring fast-acting, dual indication characteristics.
- Part of the trusted Bussmann series ensuring quality and performance.
Product Description
Eaton 170M5813D Centred Tag Fuse NH2 is a new, fast-acting fuse with a current rating of 700A and voltage rating of 690V AC. Designed primarily for use in industrial electrical applications, this fuse offers reliable short-circuit protection, especially for thyristors, diodes, and rectifiers.
It features silver-plated brass contact blades that offer exceptional conductivity and resistance to corrosion, ensuring a durable and consistent connection when mounted on open fuse bases. The fuse has compact dimensions of 72mm length, 54mm width, and 68mm height, making it suitable for installation in limited space environments.
The fuse belongs to the Bussmann series and conforms to standards such as UL, CE, IEC, and CSA. Its high rupture capacity of 200kA offers excellent protection against dangerous high current surges without arcing or burning risks. The fast-acting and dual indication characteristics offer swift disconnection and easy visual status identification.
Fast-acting protection for semiconductors and rectifiers. Highly conductive silver-plated brass blades resist corrosion. Compact size for confined space installation. 700A current rating and 690V AC voltage support high-power applications.
200kA breaking capacity safeguards equipment during faults. Low power loss of 43W for increased energy efficiency. Blade type tag with 25mm width for secure fitting. Meets UL, CE, IEC, and CSA standards for safety and quality.
This Eaton centred tag fuse is ideal for industrial, manufacturing, and electrical automation applications where fast and reliable semiconductor protection is critical. It helps ensure safe, efficient operation of complex electrical systems, substations, and motor controls.
Explore more Eaton Tag Fuses and related protective equipment in our electronics and electricals category at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This fuse has a current rating of 700A, making it suitable for high-power industrial applications.
It is rated for 690V AC, ensuring compatibility with high-voltage electrical systems.
The compact dimensions are 72mm in length, 54mm in width, and 68mm in height, allowing for installation in confined spaces.
This fuse has a breaking capacity of 200kA, which prevents arcing and burning during high current surges.
It is classified as a fast-acting, dual indication fuse, specifically a Blade type with a tag width of 25mm.
It conforms to several standards including UL, CE, IEC, and CSA, ensuring safety and quality.
The contact blades are made of silver-plated brass, which provides excellent conductivity and corrosion resistance.
Yes, it falls under application category aR, which is suitable for short-circuit protection in electrical equipment.
The power loss is rated at 43W, contributing to increased energy efficiency during operation.
The overall length of the fuse is 150mm, which may be relevant for installation considerations.
It is designed primarily for protecting thyristors, diodes, and rectifiers in electrical equipment.
Yes, its compact dimensions make it suitable for installation in confined spaces, enhancing its versatility in various applications.
