Banner SG-TL70 Series Red Flashing, Steady Effect Beacon Tower, LED Bulb 30V dc IP65
Specifications
| Country of Origin | China |
|---|---|
| Brand | Banner |
| Height | 50mm |
| Model | TL70 |
| IP Rating | IP65 |
| Mount Type | Direct |
| Bulb Type | LED |
| Series | SG-TL70 |
| Maximum Operating Temperature | 50°C |
| Current Type | DC |
| Current consumption | 420mA |
| Minimum Operating Temperature | -40°C |
| Base Diameter | 70mm |
| Terminal type | Press Fit |
| Component Type | Beacon |
| Lens Colour | Red |
| Standards/Approvals | CE |
| Maximum Supply Voltage | 30V dc |
| Housing Colour | Black |
| Light Effect | Flashing, Steady |
| Minimum Sound Level | 84dB |
| Sounder Type | Alarm |
| Maximum Sound Level | 92dB |
Key Features
- Operates on 30V DC with a current consumption of 420mA.
- Durable IP65 rated housing suitable for rugged environments.
- Features multifunction capability including flashing and steady light effects.
- Includes an LED bulb and supports user-selectable solid ON or flashing modes.
- Sounder alarm range from 84dB to 92dB enhances audible warnings.
- Operating temperature range from -40°C to 50°C ensures reliability.
- Mounts directly with press fit terminals for easy wiring.
- Constructed of UV-stabilized black housing for outdoor resistance.
Product Description
Banner's SG-TL70-R is a red flashing and steady effect beacon tower designed as part of the SG-TL70 series. It operates on a 30V DC power supply with a current consumption of 420mA and features a robust LED bulb delivering bright, uniform signals. The beacon tower has a height of 50mm and a base diameter of 70mm, making it compact for various mounting environments.
This beacon offers multifunction signaling capabilities, including steady and flashing light effects, with user-selectable modes for enhanced flexibility in automation signaling. The sounder alarm integrated with the beacon produces sound levels ranging from 84dB to a maximum of 92dB, providing effective audible warnings in industrial applications.
Engineered with an IP65 rated housing, this beacon tower ensures protection against dust and water ingress, suitable for harsh industrial conditions. The mounting is direct, and connection is facilitated via press fit terminals. The lamp uses an energy-efficient LED bulb enclosed in a UV-stabilized black housing that resists environmental degradation.
Operating temperature ranges from -40°C to 50°C, guaranteeing performance in varied climates. The product is CE certified, affirming compliance with European safety and quality standards.
Operates on 30V DC power supply with 420mA current consumption. Functions with red LED light in flashing and steady modes. Robust IP65 rated, UV-stabilized black housing for outdoor use. Sounder alarm delivering 84dB to 92dB for audible signaling.
Compact dimensions: 50mm height and 70mm base diameter. Direct mount with press fit terminal connection. CE certified for quality and safety assurance. Suitable for automation, industrial signaling, and control gear applications.
This Banner SG-TL70-R beacon tower is ideal for use in industrial automation, manufacturing processes, and control systems requiring reliable visual and audible alerts. It offers versatile installation and operation in demanding environments.
Explore more Signal Tower Components and automation signaling products on EnvMart to complement your industrial automation needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
It operates on a 30V DC power supply.
This model has a height of 50mm and a base diameter of 70mm.
It features multifunction capabilities including both flashing and steady light effects.
The current consumption is 420mA.
The sounder alarm produces sound levels ranging from 84dB to 92dB.
It has an IP65 rating, providing protection against dust and water ingress.
The operating temperature range is from -40°C to 50°C.
It mounts directly with press fit terminals for easy wiring.
It uses an energy-efficient LED bulb.
Yes, it is CE certified, ensuring compliance with European safety and quality standards.
The lens color is red.
It is suitable for industrial automation, manufacturing processes, and control systems requiring reliable visual and audible alerts.
