ABB F200 Series Residual Current Circuit Breaker 63A 4-Pole 500 mA Type A 1kA Breaking 2CSF204201R4630 F204 A S-63/0,5

Free Delivery in India | Lowest Global Shipping Charges

ABB F200 Series Residual Current Circuit Breaker 63A 4-Pole 500 mA Type A 1kA Breaking 2CSF204201R4630 F204 A S-63/0,5



Category Residual Current Circuit Breaker Brand ABB Condition New

Specifications

Country of Origin	Italy
Range	F200
Brand	ABB
Height	85mm
Model	2CSF204201R4630 F204 A S-63/0,5
Depth	69mm
Width	70mm
Mount Type	DIN Rail
Current Rating	63A
Series	F200
Terminal type	Screw
Breaking Capacity	1kA
Number of Poles	4
Standards/Approvals	IEC EN 61008, RoHS, CE
Rated AC Voltage	277V ac
Tripping Characteristics	Type A
Tripping Mechanism	Electromagnetic
Reset Actuator Type	Toggle Switch
Trip Sensitivity	500mA
Break Time	Instantaneous
Earth Leakage Protection Type	Type A

Key Features

Operates at a rated AC voltage of 277V AC with a breaking capacity of 1kA.
Features Type A tripping characteristics with a trip sensitivity of 500 mA to protect against earth leakage.
Mounts easily on DIN rails and incorporates a toggle switch reset actuator for convenience.
Complies with IEC EN 61008, RoHS, and CE standards ensuring reliable and safe operation.
Equipped with a screw terminal type and an instantaneous break time for rapid disconnection.
Utilizes an electromagnetic tripping mechanism designed for efficient circuit protection.

Product Description

The ABB 2CSF204201R4630 F204 A S-63/0,5 Residual Current Circuit Breaker (RCCB) from the renowned F200 Series provides essential protection to people and installations against earth fault currents. It offers a reliable 63A rating with 4 poles and operates at a rated AC voltage of 277V AC, ensuring robust electrical circuit safety.

This RCCB is characterized by a trip sensitivity of 500 mA with Type A tripping characteristics, suitable for detecting pulsating residual currents and alternating currents, which enhances protection against electric shock risks. The device is designed for DIN rail mounting, allowing easy installation in standard electrical panels.

The breaker has a breaking capacity of 1kA, guaranteeing high interruption capability during fault conditions, while the instantaneous break time ensures rapid disconnection to minimize damage and hazards. The electromagnetic tripping mechanism provides dependable and swift response.

Constructed with a compact form factor measuring 85mm in height, 70mm in width, and 69mm in depth, the unit fits efficiently into installations with limited space. The toggle switch reset actuator facilitates user-friendly operation, and screw terminal connections enhance secure wiring.

ABB's F200 Series RCCBs are compliant with international standards including IEC EN 61008 and directives like RoHS and CE, reflecting adherence to quality and environmental safety requirements.

Ideal for use in Industrial, Commercial, and Residential electrical installations, this RCCB helps safeguard wiring and people from electrocution hazards by detecting residual earth leakage currents.

Operates at rated AC voltage of 277V AC with a 1kA breaking capacity. Features Type A trip characteristics with 500 mA trip sensitivity for effective earth leakage protection. Includes instantaneous break time and electromagnetic tripping mechanism for prompt disconnection.

Compact dimensions and DIN rail mounting for easy installation in electrical panels. Equipped with screw terminal type and toggle switch reset actuator for secure connections and convenient reset. Complies with IEC EN 61008, RoHS, and CE standards.
