ABB Residual Current Circuit Breaker F200 Series 2 Pole 100A, 500 mA Trip Sensitivity, Type 2CSF202201R4900 F202 A S-100/0,5

Free Delivery in India | Lowest Global Shipping Charges

ABB Residual Current Circuit Breaker F200 Series 2 Pole 100A, 500 mA Trip Sensitivity, Type 2CSF202201R4900 F202 A S-100/0,5



Category Residual Current Circuit Breaker Brand ABB Condition New

Specifications

Country of Origin	Italy
Range	F200
Brand	ABB
Height	85mm
Model	2CSF202201R4900 F202 A S-100/0,5
Depth	69mm
Width	35mm
Mount Type	DIN Rail
Current Rating	100A
Series	F200
Terminal type	Screw
Breaking Capacity	1kA
Number of Poles	2
Standards/Approvals	RoHS, CE, IEC EN 61008
Rated AC Voltage	277V ac
Tripping Characteristics	Type A
Tripping Mechanism	Electromagnetic
Reset Actuator Type	Toggle Switch
Trip Sensitivity	500mA
Break Time	Instantaneous
Earth Leakage Protection Type	Type A

Key Features

Trip sensitivity of 500 mA ensures precise earth leakage detection.
Type A tripping characteristic suitable for AC and pulsating DC residual currents.
Breaking capacity of 1 kA supports robust fault interruption.
Designed for DIN rail mounting with screw terminal connections.
Electromagnetic tripping mechanism delivers instantaneous response.
Equipped with toggle switch reset actuator for easy manual operation.
Complies with RoHS, CE, and IEC EN 61008 standards for quality and safety.
Rated for 277V AC operation, ensuring compatibility with industrial electrical systems.

Product Description

ABB 2CSF202201R4900 F202 A S-100/0,5 Residual Current Circuit Breaker from the F200 series is engineered to provide advanced earth leakage protection for people and installations. It is rated for 100A current with a 2-pole configuration, suitable for controlling and protecting industrial and commercial electrical circuits.

Featuring a trip sensitivity of 500 mA and Type A tripping characteristics, this RCCB responds to both standard AC residual currents and pulsating DC currents, making it versatile for various applications. The electromagnetic instantaneous tripping mechanism offers rapid fault interruption to enhance safety.

This device is designed for DIN rail mounting, facilitating straightforward installation in control panels and distribution boards. It incorporates screw type terminals securing reliable electrical connections. The compact form factor with 85 mm height, 35 mm width, and 69 mm depth ensures efficient use of panel space.

The toggle switch actuator provides manual reset capability for user convenience. Compliance with international standards including RoHS, CE, and IEC EN 61008 guarantees adherence to safety and environmental norms.

This RCCB is rated for operation at 277V AC with a breaking capacity of 1 kA, making it suitable for protecting circuits in industrial, commercial, and residential settings. Its robust design and high-quality build ensure durable performance in demanding environments.

Trip sensitivity of 500 mA ensures precise earth leakage detection. Type A tripping characteristic suitable for complex residual current profiles. Breaking capacity of 1 kA supports safe fault interruption. DIN rail mounting enables easy integration into electrical panels.

Screw terminals provide reliable electrical connections. Electromagnetic tripping mechanism offers instantaneous protection. Toggle switch actuator allows simple manual resetting. Compliant with RoHS, CE, IEC EN 61008 standards.

Compact dimensions: 85mm (H) x 35mm (W) x 69mm (D).

This ABB RCCB is ideal for industrial automation, electrical distribution, HVAC systems, and commercial electrical safety applications, ensuring personnel and equipment protection against electrical faults. Explore more circuit breakers and related electrical protection devices to fit your industrial needs at EnvMart.
