ABB F200 Series Residual Current Circuit Breaker 100A 4-Pole 30 mA Type A 1 kA 480V ac 2CSF204401R1900 F204 A-100/0,03 AP-R

ABB 2CSF204401R1900 F204 A-100/0,03 AP-R Residual Current Circuit Breaker is a robust electrical safety device designed to provide protection against earth faults and leakage currents in electrical installations. Rated for a current of 100A and operating at 480V AC, this 4-pole breaker uses a Type A tripping characteristic with 30 mA sensitivity ensuring effective and rapid disconnection upon fault detection.

The device incorporates an instantaneous break time and electromagnetic tripping mechanism to provide fast and reliable protection suitable for a wide range of industrial, commercial, and residential applications. It is designed for simple mounting on standard DIN rails, facilitated by secure screw terminal connections.

With a breaking capacity of 1 kA, this residual current circuit breaker can safely interrupt fault currents preventing damage to systems and reducing risk of electrical hazards.

Physical dimensions of 85mm height, 70mm width, and 69mm depth allow it to fit compactly within distribution boards, making it a highly practical choice for space-limited environments. The toggle switch actuator enables straightforward resetting of the breaker following trip events.

The ABB F200 series complies with IEC EN 61008 international standards and holds RoHS and CE certifications, reflecting high-quality manufacturing standards and environmental safety.

Rated for 480V AC voltage providing reliable electrical system protection. 30 mA trip sensitivity ensures safety against earth leakage currents. Designed for DIN rail mounting with screw terminals for secure installation.

Breaking capacity of 1 kA suitable for industrial and commercial applications. Equipped with toggle switch reset actuator for easy operation. Compact dimensions: Height 85mm, Width 70mm, Depth 69mm for space-efficient installation.

Packed with electromagnetic tripping mechanism for instantaneous response. Meets IEC EN 61008 standards and RoHS and CE compliances.

This Residual Current Circuit Breaker is ideal for use in electricity distribution panels in industrial, commercial, and residential buildings, providing critical protection to electrical circuits and enhancing safety for users and devices alike. It is compatible with installations requiring high reliability and adherence to international electrical safety standards.
