ABB F200 Series Residual Current Circuit Breaker 40A 2-Pole 100mA Type A 1kA Breaking 2CSF202201R2400 F202 A S-40/0,1

Free Delivery in India | Lowest Global Shipping Charges

ABB F200 Series Residual Current Circuit Breaker 40A 2-Pole 100mA Type A 1kA Breaking 2CSF202201R2400 F202 A S-40/0,1



Category Residual Current Circuit Breaker Brand ABB Condition New

Specifications

Country of Origin	Italy
Range	F200
Brand	ABB
Height	85mm
Model	2CSF202201R2400 F202 A S-40/0,1
Depth	69mm
Width	35mm
Mount Type	DIN Rail
Current Rating	40A
Series	F200
Terminal type	Screw
Breaking Capacity	1kA
Number of Poles	2
Standards/Approvals	IEC EN 61008, CE, RoHS
Rated AC Voltage	277V ac
Tripping Characteristics	Type A
Tripping Mechanism	Electromagnetic
Reset Actuator Type	Toggle Switch
Trip Sensitivity	100mA
Break Time	Instantaneous
Earth Leakage Protection Type	Type A

Key Features

The device provides trip sensitivity of 100mA for earth leakage protection.
This circuit breaker is designed for DIN rail mounting with screw terminal type.
The breaking capacity is rated at 1 kA, ensuring reliable fault interruption.
It features an instantaneous break time and electromagnetic tripping mechanism for rapid response.
The reset actuator is a toggle switch type, facilitating easy manual control.
Its compact dimensions are 85 mm height, 69 mm depth, and 35 mm width.
The product conforms to IEC EN 61008, CE, and RoHS standards.
Manufactured in Italy, ensuring high-quality industrial standards.

Product Description

ABB 2CSF202201R2400 F202 A S-40/0,1 Residual Current Circuit Breaker is engineered for industrial and commercial electrical safety applications, providing reliable protection against fault currents to earth. Designed as part of the F200 series, this 40A 2-pole device operates at a rated AC voltage of 277V and offers a trip sensitivity of 100mA with Type A characteristics, suitable for both standard and selective installations.

The circuit breaker features a breaking capacity of 1 kA and employs an electromagnetic tripping mechanism for instantaneous fault clearing. Its toggle switch reset actuator allows for user-friendly manual operation and quick reset after tripping events. The device mounts easily on DIN rails, supported by screw-type terminals ensuring secure electrical connections.

Compact with dimensions of 85 mm height, 69 mm depth, and 35 mm width, it is compliant with international standards IEC EN 61008 alongside CE and RoHS certifications, underscoring its quality and safety credentials. Manufactured in Italy, it represents robust European engineering for protecting electrical installations in industrial, laboratory, and commercial environments.

Its earth leakage protection helps prevent electric shocks and equipment damage by detecting leakage currents, aligned with Type A earth leakage protection needs. The instantaneous break time enhances safety by rapidly disconnecting electrical faults.

The device is ideal for use in electrical distribution panels, automation systems, and industrial control circuits. Its screw terminal and DIN rail mounting eases installation and maintenance by professionals. The ABB F200 series offers an extensive range of RCCBs for varied electrical protection requirements.

Quality assurance comes from adherence to stringent European manufacturing standards and certifications. Explore the ABB F200 series for dependable, high-performance circuit protection tailored to industrial and commercial needs at EnvMart.
