TE Connectivity Push Button Switch, Latching, Panel Mount, 6.35 mm Cutout, SPDT, 28 V DC, 6A MPG106D

TE Connectivity MPG106D Push Button Switch is a high-quality, latching, panel-mounted switch designed for electrical and automation applications requiring reliable manual control. It features a single-pole double-throw (SPDT) contact configuration, supporting a contact voltage of 28 V DC and maximum switch contact current of 6A. The actuator is a natural-colored cap style, which is not supplied with the button and must be ordered separately.

This switch requires a 6.35 mm panel cutout and offers wire lug terminals for easy and secure wiring connections. The gold flash over silver clad copper contacts provide low contact resistance below 10 milliohms and are rated for longevity with over 50,000 operations. The unit is epoxy-sealed with flux-proof construction, ensuring durability in harsh industrial conditions.

Operating in temperatures ranging from -20 to +80 degrees Celsius, the switch is suitable for use in industrial automation, electrical control panels, HVAC systems, manufacturing equipment, and laboratory instrumentation. The device complies with REACH and RoHS standards, ensuring environmental safety and quality compliance.

Note that the actuator button is not included and must be sourced separately for installation. TE Connectivity's MPG series switches are known for precision and reliable operation in complex control systems requiring momentary or alternate switching.

The switch features a natural colored cap actuator for easy operation. Designed for panel mounting with a 6.35 mm cutout size. Offers a reliable latching switch operation without illumination. Wire lug type terminals ensure secure electrical connections.

Gold flash over silver clad copper contacts provide high conductivity and durability. Contact resistance is less than 10 milliohms ensuring efficient switching. Epoxy sealed, flux-proof construction enhances longevity and reliability.

Operating temperature range from -20 to +80 degrees Celsius suits diverse environments.

Choose the TE Connectivity MPG106D switch for robust, precise manual switching solutions in industrial and electrical panel applications. Browse more Push Button Switches and components at EnvMart for your automation and electrical needs.
