Intelligent LED Solutions OSLON 150 4+ PowerStar LED Array 4-LEDs Blue 1A Current ILH-OW04-DEBL-SC211-WIR200.

Intelligent LED Solutions ILH-OW04-DEBL-SC211-WIR200. is a high-performance OSLON 150 4+ PowerStar LED Array featuring four powerful blue LEDs supplied with 1 ampere current. This LED array is engineered using Osram's latest ThinGan power chip technology for superior efficiency, cool running at currents up to 1000mA, and a low thermal resistance of 7 K/W.

The compact 20 mm x 20 mm x 3.85 mm PowerStar size is built on aluminum substrates to provide excellent thermal management during extended operation, ensuring high reliability and a long lifespan of up to 100,000 hours at 70% brightness retention. The array includes integrated silicone resin lenses with a 150° angle for optimized light projection, and secondary optics are incorporated for enhanced light control.

Pre-wired with 200 mm connecting wires, the LED array simplifies integration into custom lighting assemblies and supports linking multiple PowerStars to create extended lighting chains. Its constant current output ensures consistent luminous intensity and protects the device from current spikes. Compliance with RoHS environmental standards guarantees safety and sustainability.

This LED array is ideally suited for industrial, commercial, and specialty lighting applications including general lighting, decorative lighting, task illumination, spot lighting, downlighting, retail displays, and entertainment venues. Mounting holes for M3 screws facilitate secure installation in various housings or fixtures.

Features 4 Oslon SSL 150 ThinGan LEDs for bright, reliable illumination. Employs advanced power chip technology for efficient thermal management. Compact aluminum substrate construction for durability and heat dissipation.

Pre-wired 200 mm leads for ease of wiring and modular connection. Secondary optics included for controlled light distribution. Compliant with RoHS standards for environmental safety. Power dissipation rating of 8.68 W ensures steady operation.

Luminous flux around 460 mW for effective brightness. Typical LED voltage range of 10.8 V to 14 V at rated current. Output type is constant current for stable illumination. Explore the Intelligent LED Solutions range in the LED Arrays category on EnvMart for advanced lighting components and modules.
