Eaton Non-Resettable Fuse, Radial Lead Orientation, 1A Current Rating, 250V AC, Fast Acting SS-5F-1A-BK

The Eaton SS-5F-1A-BK is a non-resettable fuse with radial lead orientation, designed for industrial and electronic circuit protection requiring a current rating of 1 ampere and an operating voltage of 250V AC. It is engineered with a fast acting fuse characteristic to protect sensitive PCB circuits from overcurrent conditions efficiently.

Featuring a robust plastic thermoplastic polyamide body, this fuse offers durability and reliable performance within an operating temperature range of -40°C to 85°C. Its compact dimensions (8.5mm length x 4.3mm width x 8.35mm height) and small lead size (0.6mm diameter and 4.3mm length) make it an excellent choice for space-constrained applications on printed circuit boards.

With a breaking capacity of 50A, the SS-5F-1A-BK fuse ensures effective interruption of electrical faults, enhancing safety and protecting electronic components. It complies with international standards including UL 94V0, RoHS, PSE, cULus, and IEC 600680, ensuring compliance and reliability in diverse industrial and commercial environments.

This fuse belongs to Eaton’s trusted SS-5F series, known for fast acting, low breaking capacity solutions widely used in industrial automation, electrical appliances, and electronic equipment manufacturing. The product is manufactured in China following strict quality standards.

Compact radial lead orientation ideal for PCB applications. Plastic thermoplastic polyamide body ensuring durability. Fast acting fuse suitable for sensitive electronic protection. Breaking capacity of 50A provides reliable circuit interruption.

Operating temperature range from -40°C to 85°C for varied environments. Precision lead dimensions with 0.6mm diameter and 4.3mm length. Compact size of 8.5mm length, 4.3mm width, and 8.35mm height. Complies with UL 94V0, RoHS, PSE, cULus, and IEC 600680 standards.

Manufactured in China adhering to Eaton’s SS-5F series specifications.

For professionals requiring reliable circuit protection, this Eaton Non-Resettable Fuse is an ideal component. Explore more circuit protection devices and fuse solutions in the Electronics & Electricals category on EnvMart.
