Ewellix Makers in Motion Electric Linear Actuator 500N Load 300mm Stroke Length 16mm/s Speed DC CAHB-10-B3A-300413AAA000-000

Ewellix Makers in Motion CAHB-10-B3A-300413AAA000-000 electric linear actuator is a compact and robust device designed for highly reliable linear motion in industrial settings. Featuring a 300mm stroke length and a maximum load capacity of 500N, it offers a speed of 16mm/s powered by a dependable DC motor. This actuator is engineered for low-load applications requiring precise and consistent movement.

The actuator’s construction includes a zinc alloy gear housing, aluminium extension and protection tubes, and powder metal gears, providing outstanding durability and corrosion resistance. Its ACME screw drive ensures smooth, self-locking functionality. Rated IP66S, it is protected against dust ingress, water, shock, and exposure to chemicals, making it suitable for demanding environments.

Operating temperature ranges from -40°C to 85°C, enabling it to perform reliably even under harsh conditions. It features a 25% duty cycle, ensuring effective intermittent operation, while the TR12 screw spindle type provides accuracy in movement. Overload protection enhances safety in application scenarios.

This actuator is maintenance-free, ensuring a long service life with minimal downtime. Its compact design suits off-highway equipment and industrial automation setups. Common applications include medical devices, factory automation, food and beverage processing, renewable energy systems such as solar, pulp and paper industries, and material handling operations.

The CAHB-10 series actuator can be used for opening and closing doors, flaps, and windows that are difficult to access. It functions efficiently without the need for limit switches, simplifying integration into various automated and manual systems.

Compact, self-locking design ideal for low-load uses. Durable zinc alloy housing with aluminium tubes and powder metal gears. ACME screw drive mechanism for reliable motion. IP66S protective rating against environmental hazards.

Wide temperature operating range from -40°C to 85°C. Maintenance-free design with a 25% duty cycle. Equipped with TR12 screw spindle type for precise control. Designed for harsh, industrial environments requiring robust actuators.

Applications include medical, automation, food & beverage, renewable energy, and material handling. Overload protection and operation without limit switches. Explore more products in Electric Linear Actuators and improve your industrial automation and mechanical power transmission systems with reliable, high-performance solutions.
