Wurth Elektronik 2-Element Uni-Directional TVS Diode Array, 6-Pin SOT-23 82400102

Wurth Elektronik 82400102 2-Element Uni-Directional TVS Diode Array in a compact 6-pin SOT-23 package delivers efficient transient voltage suppression and electrostatic discharge protection essential for modern electronic devices. This device is engineered with a complex diode configuration ensuring reliable surge protection in sensitive equipment.

With a minimum breakdown voltage of 6 V and maximum reverse stand-off voltage of 5 V, it effectively safeguards components against voltage spikes. The diode array can handle a peak pulse current of up to 6 A, providing robust transient suppression for USB 2.0, HDMI, DVI, Ethernet, Firewire, and serial bus interfaces.

This diode array operates reliably across a broad temperature range from -40°C to 125°C, making it suitable for demanding industrial, commercial, and consumer electronics applications. Its small footprint of 2.9 mm by 1.6 mm by 1.06 mm allows designers to optimize PCB space while maintaining high performance.

Surface mount packaging facilitates efficient automated PCB assembly, ensuring manufacturing scalability. The device’s maximum reverse leakage current is minimal at 5 μA, contributing to low standby energy consumption.

Wurth Elektronik’s WE-TVS series is renowned for ultralow capacitance TVS diode arrays ideal for electrostatic discharge (ESD) protection in sensitive electronic circuits exposed to high transient voltages.

This diode array features a minimum breakdown voltage of 6 V for reliable surge protection. The maximum reverse stand-off voltage is rated at 5 V to guard sensitive circuits. The device supports a maximum peak pulse current of 6 A for robust transient voltage suppression.

It has a clamping voltage of 7.7 V ensuring effective voltage limitation during surges. The operating temperature range spans from -40°C to 125°C for dependable performance under harsh conditions. Designed for USB 2.0, HDMI, DVI, Ethernet, Firewire, and serial bus interfaces for ESD protection.

Compact dimensions of 2.9 mm length, 1.6 mm width, and 1.06 mm height enable space-saving PCB layouts. The device is surface mountable and suitable for automated assembly processes. ESD protection capability extends the reliability of electronic equipment by preventing damage from electrostatic discharges.

This product is ideal for industrial, laboratory, electronics manufacturing, telecommunications, and consumer electronics sectors seeking to enhance circuit durability against voltage transients. Explore more Wurth Elektronik TVS Diode Arrays and related semiconductor protection components at EnvMart.
