Littelfuse Non-Resettable Fuse 750mA, 125V Ceramic Body Time Delay 452 Series 0452.750MRL
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 125V |
| Brand | Littelfuse |
| Body Material | Ceramic |
| Height | 2.69mm |
| Model | 0452.750MRL |
| Depth | 6.1mm |
| Width | 2.69mm |
| Current Rating | 750mA |
| Series | 452 |
| Maximum Operating Temperature | -55°C |
| Resistance | 0.36Ω |
| Package Type | Reel |
| Minimum Operating Temperature | 125°C |
| Breaking Capacity | 50A |
| Terminal Material | Gold Plated |
| Standards/Approvals | RoHS, UL 248-14, CSA |
| Fuse Characteristics | Time Delay |
Key Features
- This fuse has a current rating of 750mA and voltage rating of 125V.
- The fuse body is made of durable ceramic material suitable for surface mount applications.
- It features a time delay characteristic to accommodate inrush currents and prevent nuisance openings.
- The package type is reel, enabling efficient automated assembly.
- Breaking capacity is 50A, suitable for various electronic protection needs.
- Terminal material is gold plated to ensure reliable electrical contact.
- Operating temperature ranges from -55°C to 125°C, allowing use in diverse environments.
- Meets RoHS, UL 248-14, and CSA safety and quality standards.
Product Description
Littelfuse 0452.750MRL is a high-quality non-resettable surface mount fuse designed for reliable circuit protection in electronic devices. It features a ceramic body with a compact form factor measuring 2.69mm width, 2.69mm height, and 6.1mm depth. This fuse is rated for 750mA current and 125V voltage with a 50A breaking capacity, making it effective for safeguarding sensitive equipment against overcurrent conditions.
The time delay fuse characteristic accommodates inrush currents, reducing nuisance fuse openings in applications such as alarm systems, audio/visual equipment, computer boards, power supplies, portable telephones, and medical apparatus. The fuse terminals are gold plated to ensure high-quality electrical connections and long service life.
Operating temperature range from -55°C to 125°C allows use in a variety of industrial and commercial environments. Littelfuse 452 Series NANO2 fuses comply with RoHS, UL 248-14, and CSA standards, affirming their safety and reliability.
The product comes in a reel packaging suitable for automated manufacturing processes, improving production efficiency. This fuse is part of Littelfuse’s well-regarded series known for enhanced inrush withstand and surface mount technology, ideal for space-saving low voltage applications.
Current rating of 750mA and voltage rating of 125V. Ceramic body construction for durability and insulation. Time delay characteristic to tolerate inrush currents. Reel packaging for easy automated insertion. 50A breaking capacity for effective circuit protection.
Gold-plated terminals for reliable conductivity. Compact dimensions: 2.69mm x 2.69mm x 6.1mm. Operates reliably between -55°C and 125°C. Complies with RoHS, UL 248-14, and CSA standards. Belongs to the 452 Series NANO2 surface mount fuse range.
This Littelfuse Non-Resettable Fuse is suitable for industrial, laboratory, commercial, and electronic applications requiring dependable overcurrent protection. Explore more Littelfuse products and electronics fuses on EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The Littelfuse Non-Resettable Fuse has a current rating of 750mA and a voltage rating of 125V.
It features a breaking capacity of 50A, suitable for protecting sensitive equipment against overcurrent conditions.
The fuse body is made of ceramic material, and the terminals are gold plated to ensure reliable electrical contact.
This model has compact dimensions of 2.69mm in width, 2.69mm in height, and 6.1mm in depth.
It operates reliably within a temperature range of -55°C to 125°C, making it suitable for various environments.
This fuse features a time delay characteristic, which accommodates inrush currents and helps prevent nuisance openings.
The fuse comes in reel packaging, which facilitates efficient automated assembly processes.
It meets RoHS, UL 248-14, and CSA safety and quality standards, ensuring its reliability and safety in applications.
This model is suitable for various applications including alarm systems, audio/visual equipment, computer boards, power supplies, and medical apparatus.
The resistance of this fuse is 0.36Ω, which is relevant for its electrical performance.
Yes, the ceramic body construction of this fuse makes it suitable for surface mount applications.
This fuse is part of the 452 Series NANO2, known for enhanced inrush withstand and surface mount technology.
