SMC 125 mm Pneumatic Piston Rod Cylinder Double Acting Both Ends Tapped Air Cushion Aluminium Alloy CD85

Free Delivery in India | Lowest Global Shipping Charges

SMC 125 mm Pneumatic Piston Rod Cylinder Double Acting Both Ends Tapped Air Cushion Aluminium Alloy CD85



Category Pneumatic Piston Rod Cylinder Brand SMC Condition New

Specifications

Country of Origin	India
Brand	SMC
Body Material	Aluminium Alloy
Length	262mm
Model	CD85
Mount Type	Both Ends Tapped
Series	CD85
Maximum Operating Temperature	60°C
Stroke Length	125mm
Rod Type	Single
Action Type	Double Acting
Standards/Approvals	ISO 6432
Cushioning Type	Air Cushion
Maximum Piston Speed	1500 mm/s
Piston Rod Gender	Female
Piston Rod Thread Standard	Metric

Key Features

This pneumatic cylinder has a 125 mm stroke length and a total length of 262 mm.
It employs a single rod type with a female piston rod thread standard in metric units.
Designed for double acting operation with air cushion cushioning type.
Constructed with corrosion-resistant aluminium alloy body for durability and long service life.
Operates at a maximum temperature of 60°C and complies with ISO 6432 standards.
The cylinder supports a maximum piston speed of 1500 mm/s for efficient pneumatic control.
Easy installation through large spanner flats, supplied with piston rod locknut and nose-mounting nut.

Product Description

SMC CD85N25-125C-B Pneumatic Piston Rod Cylinder is part of the CD85 Series, designed for precise pneumatic actuation with a 125 mm bore diameter and double acting operation. Featuring a robust aluminium alloy body and an air cushion for smooth piston movement, this cylinder is engineered for industrial applications including manufacturing automation, material handling, and pneumatic control systems.

The cylinder has an overall length of 262 mm and a stroke length of 125 mm. It includes both ends tapped mounting allowing versatile installation options. The single rod design with female metric thread ensures compatibility with common pneumatic setups.

The construction uses corrosion-resistant materials to ensure longevity in demanding environments. The cylinder conforms to ISO 6432 standards, ensuring quality and interchangeability. Maximum operating temperature is 60°C, suitable for typical industrial conditions.

The cylinder supports piston speeds up to 1500 mm/s, providing fast response times critical for automated systems. Special elastomer cushion seals reduce friction and wear, enhancing performance and life span. Included accessories like piston rod locknut and nose-mounting nut simplify setup and maintenance.

Double acting pneumatic piston rod cylinder with 125 mm bore diameter. Constructed from aluminium alloy with high corrosion resistance. Both ends tapped mount for flexible installation. Air cushion cushioning type for smooth piston action.

Complies with ISO 6432 standards. Maximum operating temperature of 60°C. Supports maximum piston speeds of 1500 mm/s. Includes piston rod locknut and nose-mounting nut for convenience.

This cylinder is ideal for various industrial sectors such as manufacturing, automation equipment, and pneumatic tool systems, ensuring reliable and efficient pneumatic actuation with long service life.
