SMC 200 mm Pneumatic Piston Rod Cylinder Double Acting Both Ends Tapped Aluminium Alloy Body CD85
Specifications
| Country of Origin | Japan |
|---|---|
| Brand | SMC |
| Body Material | Aluminium Alloy |
| Length | 309mm |
| Model | CD85 |
| Mount Type | Both Ends Tapped |
| Series | CD85 |
| Maximum Operating Temperature | 60°C |
| Stroke Length | 200mm |
| Rod Type | Single |
| Action Type | Double Acting |
| Standards/Approvals | ISO 6432 |
| Cushioning Type | Air Cushion |
| Piston Rod Gender | Female |
| Piston Rod Thread Standard | Metric |
Key Features
- The cylinder body is constructed from durable aluminium alloy.
- It features both ends tapped mount type for versatile installation.
- Air cushioning reduces shock and prolongs service life.
- The rod is single type with a female piston rod thread, conforming to metric standards.
- Maximum operating temperature is 60 degrees Celsius.
- Designed according to ISO 6432 standards for precision and reliability.
- Suitable for high-speed applications with piston speeds up to 1500 mm/s.
- Constructed with corrosion-resistant materials including stainless steel barrel and piston rod.
Product Description
SMC CD85N12-200C-B pneumatic piston rod cylinder is a highly durable and precise component within the CD85 Series, designed for double acting operation suitable for industrial automation, pneumatic tooling, and fluid power control. This cylinder features a 200 mm stroke length combined with a total body length of 309 mm, making it appropriate for medium range mechanical actuation needs.
The cylinder body is made of aluminium alloy, providing a good strength-to-weight ratio, while the barrel and piston rod employ stainless steel to enhance corrosion resistance. Double-swaged anodised aluminium end caps ensure airtight sealing and long service life. The air cushioning feature reduces mechanical shock during the stroke's end positions, contributing to reliable and smooth operation.
Manufactured to comply with ISO 6432 standards and CETOP RP52P, the CD85 Series cylinders ensure 100% mounting repeatability accuracy. The unique dust seal design protects the cylinder in extremely dusty environments, extending operational life and reducing maintenance frequency. This model is well-suited for use in manufacturing automation, laboratory equipment, packaging machinery, and any application requiring precise pneumatic actuation.
Installation is simplified by including a piston rod locknut and nose-mounting nut, plus the use of large spanner flats facilitates easy assembly in constrained spaces. The metric female piston rod thread and both ends tapped mount enhance versatility for diverse setups.
The cylinder body is made of corrosion-resistant aluminium alloy. Double acting pneumatic piston rod cylinder with 200 mm stroke length. Complies with ISO 6432 standards for pneumatic cylinders. Maximum piston speed of 1500 mm/s for high-speed applications.
Equipped with abrasion-resistant seals and a replaceable piston rod seal. Features air cushioning for shock absorption during operation. Designed for use in dusty environments with high dust resistance. Includes piston rod locknut and nose-mounting nut for easy installation.
Operating temperature up to 60 degrees Celsius. Constructed with stainless steel barrel and piston rod.
This Pneumatic Piston Rod Cylinder is ideal for industrial, manufacturing, assembly line, and automation uses requiring reliable and consistent force delivery. Browse EnvMart's selection of pneumatic cylinders for complementary components and accessories.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The stroke length of this pneumatic piston rod cylinder is 200 mm.
The maximum operating temperature for this model is 60 degrees Celsius.
The cylinder body is constructed from aluminium alloy, while the barrel and piston rod are made of stainless steel for enhanced corrosion resistance.
This cylinder features a both ends tapped mount type, allowing for versatile installation options.
This unit has a maximum piston speed of 1500 mm/s, making it suitable for high-speed applications.
This pneumatic cylinder is designed according to ISO 6432 standards, ensuring precision and reliability.
It is equipped with air cushioning to reduce mechanical shock during operation, contributing to smooth performance.
The total body length of this cylinder is 309 mm.
This model features a single type rod with a female piston rod thread that conforms to metric standards.
This pneumatic cylinder is suitable for applications in manufacturing automation, laboratory equipment, packaging machinery, and any requiring precise pneumatic actuation.
Included accessories for installation are a piston rod locknut and a nose-mounting nut, which facilitate easy assembly.
The piston rod thread is female, conforming to metric standards.
