Schurter 16A T Ceramic Cartridge Fuse 6.3 x 32 mm 500V AC Time Delay 8020.5023.G

Free Delivery in India | Lowest Global Shipping Charges

Schurter 16A T Ceramic Cartridge Fuse 6.3 x 32 mm 500V AC Time Delay 8020.5023.G

Name: Schurter 16A T Ceramic Cartridge Fuse 6.3 x 32 mm 500V AC Time Delay 8020.5023.G
Brand: Schurter
SKU: 210189
Price: 1.04 USD
Availability: InStock



Category Cartridge Fuse Brand Schurter Condition New

Specifications

Country of Origin	China
Voltage	500V ac
Diameter	6.3mm
Brand	Schurter
Body Material	Ceramic
Model	8020.5023.G
Overall Length	32mm
Current Rating	16A
Series	SHT 6.3x32
Maximum Operating Temperature	85°C
Minimum Operating Temperature	-40°C
Standards/Approvals	UL, UKCA, RoHS, cURus, CE
Fuse Characteristics	Time Delay
Fuse Size	6.3 x 32 mm
UL File Number	E41599 listed
Schurter 16A T Glass Cartridge Fuse, 6.3 x 32mmBrand	Schurter

Key Features

The ceramic cylindrical body ensures high durability and thermal stability.
Rated for a maximum operating temperature of 85°C and minimum of -40°C.
Fuse is time-delay (slow blow) suitable for pulse-shaped continuous currents.
Nickel-plated copper alloy end caps provide excellent conductivity and corrosion resistance.
Breaking capacity of 1500A for AC and 1000A for DC applications.
Compliance with UL, UKCA, RoHS, cURus, and CE standards.
Commonly used in 3-phase systems, DC systems, frequency converters, photovoltaic, and power electronics.
Compact size of 6.3 mm diameter and 32 mm length fits standard fuse holders.

Product Description

Schurter 8020.5023.G 16A T Ceramic Cartridge Fuse with a 6.3 x 32 mm ceramic body and 500V AC rating provides reliable, time-delay fuse protection for electrical systems. It is designed to protect equipment in demanding industrial, commercial, and electrical automation applications.

This cartridge fuse features a robust ceramic cylindrical body, which ensures thermal resistance and mechanical strength. It has nickel-plated copper alloy end caps on both ends and tin-plated copper axial leads for excellent conductivity and corrosion resistance.

The fuse operates effectively within a temperature range of -40°C to 85°C and provides a breaking capacity of up to 1500A at AC and 1000A at DC. Its time-delay (slow blow) characteristic makes it suitable for applications with transient current surges, such as frequency converters and photovoltaic systems.

Certifications include UL 248-14, CSA C22.2 No. 248.14, UKCA, RoHS, and cURus, ensuring compliance with international safety and quality standards. The fuse is particularly suitable for use in three-phase systems, DC systems, power electronics, and other industrial electrical equipment requiring dependable protection.

This fuse series, SHT 6.3x32, offers an optimal combination of performance and safety in a compact form factor of 6.3 mm diameter and 32 mm length, compatible with a wide range of fuse holders and clips. It is manufactured in China, adhering to stringent quality controls.

The ceramic cylindrical body ensures high durability and thermal stability. Rated for a maximum operating temperature of 85°C and minimum of -40°C. Fuse is time-delay (slow blow) suitable for pulse-shaped continuous currents.

Nickel-plated copper alloy end caps provide excellent conductivity and corrosion resistance. Breaking capacity of 1500A for AC and 1000A for DC applications. Complies with UL, UKCA, RoHS, cURus, and CE standards for safety and quality.

Used in 3-phase, DC systems, frequency converters, photovoltaic, and power electronics. Compact size fits standard fuse holders and clips. Explore a wide range of Cartridge Fuses and electrical protection components in our Electronics & Electricals category for industrial and laboratory applications.
