C & K IP40 Blue Tactile Switch Button, SPST 50mA 12 V DC Surface Mount

Name: C & K IP40 Blue Tactile Switch Button, SPST 50mA 12 V DC Surface Mount
Brand: C & K
SKU: 204306
Price: 0.36 USD
Availability: InStock



Category Tactile Switch Brand C & K Condition New

Specifications

Country of Origin	China
Brand	C & K
Height	2mm
Length	6mm
Model	IP40
IP Rating	IP40
Width	6mm
Mount Type	Surface
Series	PTS
Maximum Operating Temperature	60°C
Contact Configuration	SPST
Switch Configuration	(On)-Off
Minimum Operating Temperature	-20°C
Terminal type	Terminal
Standards/Approvals	RoHS
Switch Operation	Momentary
Actuator Colour	Blue
Contact DC Voltage	12V dc
Actuator Style	Button
Actuator Orientation	Straight
Switch Contact Current	50mA
Operating Force	1.6N
Mechanical Life	200000Cycles

Key Features

The switch features a 6 x 6 mm footprint suitable for compact applications.
It operates with a low force of 1.6N for smooth tactile feedback.
Designed with a blue actuator and a straight button style for easy identification.
The switch supports a mechanical life of 200000 cycles ensuring durability.
Suitable for industrial, consumer electronics, and instrumentation applications.
Operates reliably between temperatures of -20°C to 60°C.
Non-illuminated with a surface mount style for flexible PCB integration.
Certified RoHS compliant and manufactured in China.

Product Description

C & K PTS645SM50SMTR 92 LFS Blue Tactile Switch is a high-quality surface mount tactile switch featuring a compact 6 x 6 mm footprint and a 2 mm height profile. It operates as a Single Pole Single Throw (SPST) momentary switch suitable for low current applications, with a contact rating of 50mA at 12 V DC.

The switch’s IP40 rating offers protection against solid objects greater than 1 mm, making it ideal for indoor electronic devices where dust ingress is minimal. The blue actuator provides easy visual identification and the straight button style ensures consistent actuation force of 1.6N, providing excellent tactile feedback for precise control inputs.

With a mechanical life rated at 200000 cycles, this tactile switch is designed for long-term reliability in demanding conditions. It performs within a temperature range from -20°C to 60°C, supporting a wide range of operating environments.

This switch is ideal for applications including industrial instrumentation, consumer products, and computers where compact, reliable momentary tactile action is required. It comes RoHS compliant, ensuring it meets environmental and safety standards.

The switch footprint is 6 x 6 mm with a 2 mm height. SPST contact configuration with a momentary (on-off) operation. Rated for 50mA contact current at 12 V DC. Blue actuator with straight button style and surface mount termination.

Durability of 200000 mechanical cycles and operating force of 1.6N. Operating temperature range from -20°C to 60°C. IP40 rated enclosure for protection against small solids. Non-illuminated standard PTS series from C & K.

RoHS compliant and made in China.

This Tactile Switch is well-suited for use in electrical, automation, manufacturing, instrumentation, and consumer electronics industries where reliable user interface switches are essential. Explore more switches and components in the Electronics & Electricals category at EnvMart.
