Schneider Electric TeSyS D Contactor 3-Pole 40 A 18.5 kW 110V AC/DC Coil 130V Control Voltage LC1D40AEHE
Specifications
| Country of Origin | India |
|---|---|
| Brand | Schneider Electric |
| Function | Motor Control, Resistive Load |
| Length | 55mm |
| Model | LC1D40AEHE |
| Depth | 122mm |
| Width | 120mm |
| Mount Type | DIN Rail |
| Series | TeSys D |
| Power Rating | 18.5kW |
| Maximum Operating Temperature | 60°C |
| Minimum Operating Temperature | -25°C |
| Terminal type | Screw |
| Number of Poles | 3 |
| Standards/Approvals | CCC, CSA, EAC, IEC, RoHS, UL |
| Contact Voltage | 690V ac |
| Coil Voltage | 110V ac/dc |
| Normal State Configuration | 3 NO |
| Better World Claim | Designed for Disassembly |
| Contact Current | 40A |
| Number of Auxiliary Contacts | 2 |
| Auxiliary Contact Configuration | 1 NO/1 NC |
| Operational Current Ie | 40A |
| Control Circuit Voltage Uc | 130V |
| Contactor Application | Motor Control, Resistive Load |
| Pole and Throw Configuration | 3PST |
| Screw connections | IP20 finger-safe terminals with both North American and International terminal markings |
| AC-1 | This applies to all AC devices with a power factor of at least 0.95. Example of use: resistive load, heating, distribution |
| AC-3 | This applies to squirrel cage motors where breaking occurs while the motor is running. Example of use: all squirrel cage motors, lifts, escalators, conveyors, bucket elevators, compressors, pumps, mixers, air conditioning units |
| Schneider Electric LC1D Series Contactor, 3-Pole, 18.5 kW, 3NOBrand | Schneider Electric |
Key Features
- Designed for motor control and resistive load applications.
- Equipped with 3 normally open main contacts and 2 auxiliary contacts.
- Operates with 110V AC/DC coil and 130V control voltage.
- Mounts on DIN rail or panel with screw connections.
- IP20 finger-safe terminals with international markings.
- Wide operating temperature range from -25°C to 60°C.
- Complies with CCC, CSA, EAC, IEC, RoHS, and UL standards.
- Built for long mechanical and electrical life.
Product Description
Schneider Electric LC1D40AEHE TeSyS D Contactor is a robust and reliable 3-pole contactor with a rated current of 40 A and power rating of 18.5 kW, featuring an 110V AC/DC coil and 130V control voltage. It is designed primarily for motor control and resistive load applications in industrial and commercial environments.
The contactor supports 3 normally open main contacts (3 NO) and 2 auxiliary contacts configured as 1 normally open and 1 normally closed, enabling advanced switching capabilities. It offers versatile mounting options including DIN rail and panel mounting with screw connections. The IP20 finger-safe terminals provide safety and meet both North American and international terminal marking requirements.
Operating within a temperature range of -25°C to 60°C, this contactor is built for demanding industrial conditions, ensuring long mechanical and electrical life compliance with major standards such as CCC, CSA, EAC, IEC, RoHS, and UL.
The TeSyS D range contactors feature a wider control voltage band and lower power consumption for their coils, making them energy efficient. These contactors also include a bidirectional peak limiting diode suppressor to protect the coil, making them suitable for motor starters, lifts, conveyors, pumps, compressors, and air conditioning units.
Designed for motor control and resistive load applications. Three-pole design with 40 A contact current and 18.5 kW power rating. 110V AC/DC coil voltage and 130V control circuit voltage. 2 auxiliary contacts with 1 NO and 1 NC configuration.
DIN rail and panel mounting options with screw terminals. IP20 finger-safe terminals with international markings. Wide operating temperature range from -25°C to 60°C. Compliance with CCC, CSA, EAC, IEC, RoHS, and UL standards.
This Schneider Electric contactor is ideal for industrial automation, manufacturing, HVAC systems, water treatment plants, and other commercial electrical control systems. It ensures high reliability, easy installation, and efficient operation, reducing energy consumption and maintenance needs.
Explore the Automation & Control Gear section at EnvMart for more Schneider Electric TeSyS D Contactors and related industrial automation products.
