KEMET Polypropylene Capacitor 220 pF ±5% 1 kV DC 400 V AC Radial Lead R76QD0220SE00J

The KEMET R76QD0220SE00J is a high-quality polypropylene film capacitor offering a capacitance of 220 pF with a precise ±5% tolerance. This capacitor is designed with double metallized polypropylene film electrodes and encapsulated in a self-extinguishing plastic case rated to UL 94V-0 standards which ensures excellent durability and safety in various electronic and industrial applications.

Rated for a DC voltage of 1 kV and an AC voltage of 400 V, this capacitor is ideal for use in high frequency applications, including snubber circuits, silicon-controlled rectifier (SCR) commutation, and suppression in switched mode power supplies (SMPS). The radial lead type and 7.5 mm lead pitch allow for straightforward mounting on printed circuit boards.

The operating temperature range from -55°C to 105°C, along with automotive standard AEC-Q200 qualification, makes this capacitor highly reliable for automotive and industrial electronics exposed to demanding environments. Its low equivalent series resistance (ESR) of 8.68 Ω and a very low dissipation factor of 0.0003% contribute to efficient performance with minimal energy loss.

The capacitor's construction ensures self-healing capabilities, enhancing its longevity and safety during voltage spikes or transient surges. Dimensions of approximately 10 mm length, 8 mm height, and 3 mm width support compact integration into electronic assemblies.

This product complies with IEC 60286-2 and RoHS standards, endorsing environmental safety and product quality. It is packaged in bags suitable for handling and bulk use in manufacturing.

Typical applications include high voltage and high current circuits, deflection circuits in televisions, snubber circuits, and other industrial or automotive electronics requiring stable and reliable film capacitors.

Explore the comprehensive range of KEMET film capacitors for robust solutions in electronics and industrial applications at EnvMart. Constructed with polypropylene film and double metallized polyester electrodes. Encapsulated in a UL 94V-0 rated, self-extinguishing, solvent-resistant plastic case.

Lead pitch of 7.5 mm with radial terminal type for easy PCB mounting. Operating temperature range from -55°C to 105°C suitable for harsh conditions. Meets automotive standard AEC-Q200 and IEC 60286-2, RoHS compliant. Features low equivalent series resistance (8.68 Ω) and minimal dissipation factor (0.0003%).

Designed for suppression in switched mode power supplies and high voltage, high current circuits. Size dimensions approximately 10 mm length, 8 mm height, and 3 mm width for compact installation. Available packaged in a bag for bulk handling and assembly.
