Vishay 600 V 16 A Ultrafast Plastic Rectifier General Purpose 3-Pin TO-220AB FEP16JT-E3/45

Vishay FEP16JT-E3/45 is a high-performance ultrafast plastic rectifier designed for general purpose semiconductor applications. It operates at a maximum continuous forward current of 16 A and withstands peak reverse repetitive voltages up to 600 V. The device utilizes a 3-pin TO-220AB package suitable for through-hole mounting, enabling easy integration into industrial, automotive, and electronic circuit boards.

This rectifier offers a peak reverse recovery time of only 50 nanoseconds, which significantly reduces switching losses and improves efficiency in high-speed switching power supplies, inverters, and motor control circuits. The peak non-repetitive forward surge current rating of 125 A provides robust transient tolerance, ensuring reliability during surge conditions.

The device features a common cathode diode configuration, making it compatible with many rectifier bridge arrangements. Its operating temperature range from -55°C to 150°C allows it to function reliably in demanding environmental conditions, including automotive and industrial environments where thermal stresses are prevalent.

Physical dimensions are compact, measuring 10.54 mm in length, 8.89 mm in height, and 4.7 mm in width, enabling space-efficient designs. Vishay has engineered this rectifier to meet important industry standards such as RoHS 2002/95/EC, UL 94V-0 for flammability, and WEEE 2002/96/EC for waste electrical and electronic equipment. Additionally, the product meets the automotive standard AEC-Q101, confirming its fitness for vehicle-related applications.

Features a 3-pin TO-220AB package for through-hole mounting. Maximum continuous forward current of 16 A for sustained operation. Peak reverse repetitive voltage of 600 V supports versatile applications. Fast peak reverse recovery time of 50 ns enhances switching efficiency.

Wide operating temperature range from -55°C to 150°C for durability. Common cathode diode configuration suitable for bridge circuits. High surge current capacity of 125 A protects against transients. Complies with RoHS, UL, and WEEE environmental standards.

Automotive compliant with AEC-Q101 for enhanced reliability. Compact dimensions aid in efficient circuit design.

This Vishay ultrafast plastic rectifier is ideal for use in industrial electronics, automotive systems, power supplies, and manufacturing processes requiring efficient, high-speed diode performance. The combination of robust electrical ratings and industry certifications makes it a reliable choice for electronics engineers and designers seeking quality discrete semiconductor components.
