TDK-Lambda CC-E Series 10W DC/DC Converter 24V DC Input, 12V DC Output, 1A Output Current, Through Hole Mount CC10-2412SF-E

Free Delivery in India | Lowest Global Shipping Charges

TDK-Lambda CC-E Series 10W DC/DC Converter 24V DC Input, 12V DC Output, 1A Output Current, Through Hole Mount CC10-2412SF-E

Name: TDK-Lambda CC-E Series 10W DC/DC Converter 24V DC Input, 12V DC Output, 1A Output Current, Through Hole Mount CC10-2412SF-E
Brand: TDK-Lambda
SKU: 199328
Price: 48.75 USD
Availability: InStock



Category DC/DC Converter Brand TDK-Lambda Condition New

Specifications

Country of Origin	Japan
Voltage	Converters / DC-DC Converters TDK-Lambda CC-E DC/DC Converter, 12V dc/ 1 A, 24V
Brand	TDK-Lambda
Efficiency	87%
Operating Temperature Range	-40 to +85°C
Length	35.56mm
Model	CC10-2412SF-E
Depth	8.5mm
Gross Weight	10g
Width	17.52mm
Mount Type	Through Hole
Series	CC-E
Maximum Operating Temperature	85°C
Package Type	DIP
Minimum Operating Temperature	-40°C
Number of outputs	1
Maximum Output Power	10W
Maximum Input Voltage	24V dc
Standards/Approvals	CE, cULus, EN 60950-1, NEMKO, UL CSA 60950-1
Number of Pins	7
Output Voltage 1	12V dc
Output Current 1	1A
Output Voltage Adjustment Range	11.4 → 15 V
Isolation Voltage	500V ac

Key Features

Compact DIP package with dimensions 35.56mm by 17.52mm by 8.5mm.
Single output voltage adjustable from 11.4 volts to 15 volts.
High isolation voltage of 500 volts AC for safe operation.
Efficient design with 87 percent efficiency to reduce heat generation.
Certified to CE, cULus, EN 60950-1, NEMKO, and UL CSA standards.
Operating temperature range from minus 40 degrees Celsius to 85 degrees Celsius.
7-pin through-hole mounting ensures reliable PCB integration.

Product Description

TDK-Lambda CC10-2412SF-E is a member of the CC-E series of DC/DC converters, providing a robust 10W single output power solution. It accepts a 24V DC input and supplies a regulated 12V DC output at 1A current, designed for industrial and electronic applications requiring stable voltage conversion.

This converter is housed in a compact DIP package measuring 35.56mm in length, 17.52mm in width, and 8.5mm in depth, suitable for through-hole mounting onto printed circuit boards. The output voltage can be adjusted within an 11.4V to 15V range, offering flexibility for various circuit requirements.

With an isolation voltage of 500V AC, the converter ensures electrical safety and noise immunity between input and output. Operating efficiently at 87%, it minimizes energy loss and heat dissipation, contributing to reliability and longer service life.

Its wide operating temperature range from -40°C to 85°C allows deployment in harsh industrial environments and temperature-variable settings. The device carries multiple certifications, including CE, cULus, EN 60950-1, NEMKO, and UL CSA 60950-1, affirming compliance with international safety and quality standards.

The TDK-Lambda CC10-2412SF-E DC/DC Converter is ideal for applications in industrial automation, telecommunications, instrumentation, power supply modules, and embedded systems where stable and reliable voltage conversion is critical.

Compact through-hole DIP package for easy PCB installation. Single regulated output with adjustable voltage range. High isolation voltage for enhanced electrical safety. Wide operating temperature range for industrial environments.

High conversion efficiency reduces power losses. Multiple international safety certifications ensure product reliability. Lightweight design at approximately 10 grams. Discover more products in the DC/DC Converter category on EnvMart for your power supply needs and industrial applications.
