KEMET R46 Film Capacitor X2 Safety Class, ±20% Tolerance, 22 nF, 310V AC/DC Through Hole R463I22204001M
Specifications
| Country of Origin | China |
|---|---|
| Capacitance Range | 0.01 - 10 μF |
| Display | screen |
| Brand | KEMET |
| Height | 11mm |
| Length | 18mm |
| Model | R463I22204001M |
| Packaging | Bag |
| Width | 5mm |
| Mount Type | Through Hole |
| Series | R46 |
| Maximum Operating Temperature | 110°C |
| Tolerance | ±20 % |
| Capacitance | 22nF |
| Minimum Operating Temperature | -40°C |
| Terminal type | Radial |
| Dissipation Factor | 0.1% |
| Lead Length | 30mm |
| Standards/Approvals | RoHS |
| Pin Count | 2 |
| Rated AC Voltage | 310V ac |
| Rated DC Voltage | 310V dc |
| Lead Pitch | 15mm |
| Lead Diameter | 0.6mm |
| Suppression Class | X2 |
| Capacitance tolerance | ±20%, ±10% |
| Lead Spacing | 10.0 mm to 37.5 mm |
Key Features
- The capacitor is rated for a maximum operating temperature of 110°C and a minimum of -40°C.
- Designed for EMI suppression with X2 safety classification and radial terminal type.
- Lead pitch measures 15 mm with lead length of 30 mm and a lead diameter of 0.6 mm.
- Constructed using metallised polypropylene film with self-healing properties enhancing durability and reliability.
- The capacitor complies with RoHS standards and is manufactured in China.
- Applicable for worldwide electromagnetic interference suppression in across-the-line applications requiring X2 safety class.
- Capacitance tolerance variations include ±20% and ±10%, with a dissipation factor of 0.1%.
- Operating temperature range of -40°C to +110°C with climatic category of 40/110/56 per IEC 60068-1.
Product Description
KEMET R463I22204001M Film Capacitor X2 safety class, rated at 22 nF capacitance and ±20% tolerance, supports a rated voltage of 310 V AC and DC. It utilizes through hole mounting with radial leads, fitting applications requiring efficient EMI suppression and enhanced safety standards.
This metallised polypropylene capacitor series features self-healing properties that increase reliability and lifespan. The capacitor is designed for operating temperatures ranging from -40°C to +110°C, complying with IEC climatic category 40/110/56.
The capacitor dimension measures 18 mm length, 11 mm height, and 5 mm width, with a lead pitch of 15 mm and lead length of 30 mm with 0.6 mm lead diameter, making it suitable for precise through hole circuit board assembly.
Key technical characteristics include a dissipation factor of 0.1%, capacitance tolerance of ±20%, and compliance with RoHS directives. It is manufactured in China and meets EN132400 class X2 safety standards along with UL1414 approvals including ENEC, UL, cUL, and CQC certifications.
This capacitor is intended for worldwide use in electromagnetic interference (EMI) suppression for across-the-line applications that require X2 safety classification. It is not designed for use in series with mains setups where capacitor failure might expose electric shock risk.
The capacitor operates reliably in a wide temperature range from -40°C to +110°C. It features metallised polypropylene film construction providing self-healing capability. Lead spacing of 15 mm and radial terminal type for easy PCB mounting.
Compliance with major international safety and environmental standards ensures suitability for industrial and commercial electronic applications. Applications include EMI suppression in electrical circuits to prevent interference and maintain product safety.
This KEMET R46 Film Capacitor is a dependable component for industries such as electronics manufacturing, power supply equipment, and EMI noise reduction in various electrical assemblies. It is a product designed to meet rigorous safety and quality demands.
Explore more in our Electronics Components category at EnvMart for high-quality capacitors and passive components meeting industrial standards.
Explore more products in our Film Capacitors category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has a capacitance of 22 nF.
It is rated for 310 V AC and 310 V DC.
The operating temperature range is from -40°C to +110°C.
It utilizes through hole mounting with radial leads.
The lead pitch measures 15 mm.
The dimensions are 18 mm in length, 11 mm in height, and 5 mm in width.
It has a dissipation factor of 0.1%.
This capacitor is classified as X2 for safety, suitable for EMI suppression applications.
It is constructed using metallised polypropylene film, which provides self-healing properties.
Yes, it complies with RoHS standards.
It is suitable for worldwide electromagnetic interference suppression in across-the-line applications.
The capacitance tolerance is ±20%, with additional options of ±10%.
