Telemecanique Sensors Block Ultrasonic Proximity Sensor M12 Thread Size 100 mm Maximum Detection 24V DC XX7F1A2PAL01M12
Specifications
| Country of Origin | United States |
|---|---|
| Brand | Telemecanique Sensors |
| Dimensions | H19mm x W7.6mm x D33mm |
| Response time | 4ms |
| Operating Temperature Range | -20 to +65 °C |
| Length | 19mm |
| Model | XX7F1A2PAL01M12 |
| Depth | 33mm |
| IP Rating | IP67 |
| Width | 8mm |
| Housing Material | Plastic |
| Output type | PNP |
| Series | XX |
| Maximum Operating Temperature | 65°C |
| Thread Size | M12 |
| Minimum Operating Temperature | -20°C |
| Switching Current | 100mA |
| Terminal type | M12 |
| Body Style | Block |
| Maximum dc Voltage | 24V dc |
| Maximum Switching Frequency | 100Hz |
| Standards/Approvals | IEC 60947-5-2 |
| Maximum Supply Voltage | 24V |
| Maximum Detection | 100mm |
| Operating distance | 6.4 to 102mm (fixed) |
| Minimum object size to be detected | 2.5mm |
| Overall beam angle | 14° |
Key Features
- Features a robust M12 thread size for secure mounting.
- Operates with a PNP output type and 100 mA switching current.
- Constructed with durable plastic housing and IP67 protection rating.
- Operates reliably within a temperature range of -20°C to 65°C.
- Designed with a response time of 4 ms and maximum switching frequency of 100 Hz.
- Suitable for detecting objects of minimum size 2.5 mm and overall beam angle of 14 degrees.
- Complies with IEC 60947-5-2 standards ensuring quality and safety.
- Compact block body style with dimensions H19 mm x W7.6 mm x D33 mm.
Product Description
Telemecanique Sensors XX7F1A2PAL01M12 Block Ultrasonic Proximity Sensor with M12 thread size delivers reliable and precise detection up to 100 mm using ultrasonic technology. This sensor features a plastic housing with IP67 ingress protection, making it suitable for harsh industrial environments.
The sensor operates on a 24V DC power supply with a maximum current of 100mA and provides a PNP output type for easy integration into automation systems. It has a fast response time of 4 ms and can switch at frequencies up to 100 Hz, supporting efficient object detection even on fast-moving conveyors or automated machinery.
Designed to detect objects as small as 2.5 mm with an overall beam angle of 14°, this block-style sensor is compact with dimensions of 19 mm height, 7.6 mm width, and 33 mm depth. It withstands operating temperatures from -20°C to 65°C, accommodating a wide range of industrial applications.
Compliant with IEC 60947-5-2 standards, this sensor is recognized for safety and reliability. Typical applications include food and beverage processing, packaging, automotive industry monitoring, detection of liquids, powders, glass bottles, and presence monitoring on conveyors.
This ultrasonic proximity sensor is manufactured in the United States and designed for demanding industrial automation and control gear needs, providing accurate detection of materials including metal, plastic, liquid, and varying colors without contact.
Robust M12 thread size enables secure mounting in industrial setups. Plastic housing with IP67 rating ensures protection against dust and water. Supports PNP output with a maximum switching current of 100mA. Fast response time of 4 ms facilitates high-speed applications.
Operating temperature range from -20 to +65 °C for diverse environments. Compact dimensions fit space-constrained installations. Compliance with IEC 60947-5-2 standard guarantees quality and safety. Precision detection for objects as small as 2.5 mm with a 14° beam angle.
Explore more Ultrasonic Proximity Sensors and industrial automation products at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum detection range of this model is 100 mm.
It operates reliably within a temperature range of -20°C to 65°C.
This unit features a PNP output type for integration into automation systems.
The dimensions are 19 mm in height, 7.6 mm in width, and 33 mm in depth.
The response time is 4 ms, allowing for quick detection.
It can detect objects as small as 2.5 mm.
The maximum switching frequency is 100 Hz.
This sensor has an IP67 rating, providing protection against dust and water.
The housing is constructed from durable plastic.
It complies with IEC 60947-5-2 standards for quality and safety.
The maximum switching current is 100 mA.
It features a robust M12 thread size for secure mounting in industrial setups.
