Schneider Electric TeSys D 3-Pole Contactor, 110V AC Coil, 9A, 4kW, 3 NO Auxiliary Contacts LC2D09F7
Specifications
| Country of Origin | India |
|---|---|
| Brand | Schneider Electric |
| Function | Motor Control, Resistive Load, Reversing |
| Length | 77mm |
| Model | LC2D09F7 |
| Depth | 86mm |
| Width | 90mm |
| Mount Type | DIN Rail |
| Series | LC2D |
| Power Rating | 4kW |
| Maximum Operating Temperature | 50°C |
| Minimum Operating Temperature | -25°C |
| Terminal type | Screw |
| Number of Poles | 3 |
| Standards/Approvals | CCC, CSA, EAC, IEC, RoHS, UL |
| Contact Voltage | 690V ac |
| Coil Voltage | 110V ac |
| Normal State Configuration | 3 NO |
| Better World Claim | Designed for Disassembly |
| Contact Current | 9A |
| Number of Auxiliary Contacts | 2 |
| Auxiliary Contact Configuration | 1 NO/1 NC |
| Operational Current Ie | 9A |
| Control Circuit Voltage Uc | 110V ac |
| Contactor Application | Motor Control, Resistive Load |
| Pole and Throw Configuration | 3 |
| Screw connections | IP20 finger-safe terminals with both North American and International terminal markings |
| AC-1 | This applies to all AC devices with a power factor of at least 0.95. Example of use: resistive load, heating, distribution |
| AC-3 | This applies to squirrel cage motors where breaking occurs while the motor is running |
| Example of use | all squirrel cage motors, lifts, escalators, conveyors, bucket elevators, compressors, pumps, mixers, air conditioning units |
Key Features
- Reversing operation with built-in mechanical interlock prevents simultaneous forward and reverse motor driving.
- Screw clamp terminals ensure secure wiring connections.
- Long mechanical lifespan rated at 15 million operations for durability.
- Rapid switching with opening time from 4 to 19ms and closing time from 12 to 22ms.
- Wide operating temperature range of -25°C to 50°C for demanding environments.
- Compact dimensions (77mm length, 90mm width, 86mm depth) fit easily into control panels.
- Equipped with 3 normally open poles and 2 auxiliary contacts (1 NO/1 NC) for versatile applications.
- DIN rail mountable for easy installation flexibility.
Product Description
Schneider Electric LC2D09F7 TeSys D Series 3-Pole Contactor features a 110V AC coil designed for motor control and resistive load applications in industrial environments. The product delivers a contact current of 9A and supports a power rating of 4kW at 110V AC. It offers reliable reversing functionality, allowing controlled motor rotation direction with a mechanical interlock to prevent simultaneous forward and backward switching, enhancing operational safety.
The contactor is constructed with screw clamp terminals providing secure and finger-safe IP20 connections, supporting both North American and international terminal markings. It is compact with dimensions 77mm (L) x 90mm (W) x 86mm (D), making it suitable for space-limited control panels. The device operates effectively in temperature ranges from -25°C to 50°C, enabling use in demanding industrial environments such as process control, food production, and battery manufacturing.
Included are 3 normally open main poles and 2 auxiliary contacts configured as 1 NO and 1 NC, allowing added switching capabilities and signal feedback. The contactor supports mounting via DIN rail or panel screws, facilitating ease of installation. Its long mechanical lifespan of 15 million operations ensures extended reliable service. The opening and closing times range from 4 to 19 milliseconds and 12 to 22 milliseconds respectively, allowing fast and efficient switching cycles.
The LC2D09F7 is compliant with international standards including CCC, CSA, EAC, IEC, RoHS, and UL, ensuring safety and quality requirements are met. This product is ideal for industrial applications requiring precise motor control and robust load switching performance.
Reversing motor control with built-in mechanical interlock for safety. Screw clamp terminals for secure wiring connections. High durability with a mechanical lifespan of 15 million operations. Fast switching times of 4-19 ms opening and 12-22 ms closing.
Wide operating temperature range from -25°C to 50°C. Compact size for easy mounting in control panels. Auxiliary contacts for enhanced control and signaling. Mounting flexibility via DIN rail or panel screws. Certified with major international safety and quality standards.
EnvMart offers a comprehensive selection of Schneider Electric Contactors for automation, industrial control, and motor operation needs. Explore our catalog to select the appropriate contactor and control gear for your applications.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The LC2D09F7 contactor has a power rating of 4kW at 110V AC.
This model supports a maximum contact current of 9A.
The dimensions are 77mm in length, 90mm in width, and 86mm in depth.
It features screw clamp terminals that provide secure and finger-safe IP20 connections.
The contactor operates within a temperature range of -25°C to 50°C.
This model is equipped with 2 auxiliary contacts, configured as 1 normally open (NO) and 1 normally closed (NC).
The opening time ranges from 4 to 19 milliseconds, while the closing time ranges from 12 to 22 milliseconds.
Yes, it is designed for reversing operation with a built-in mechanical interlock to prevent simultaneous forward and reverse motor driving.
It can be mounted using DIN rail or panel screws, providing installation flexibility.
This contactor is compliant with several international standards including CCC, CSA, EAC, IEC, RoHS, and UL.
It is suitable for motor control and resistive load applications, including use in process control, food production, and battery manufacturing.
It has a long mechanical lifespan rated at 15 million operations, ensuring extended service.
