RS PRO Circular Connector M12 Socket Female 2 Contacts Cable Push Pull IP67 250V 13A 124-6700

RS PRO 124-6700 is a high-quality Industrial Circular Connector featuring 2 gold-plated brass contacts in a cable mount M12 socket, designed for demanding applications.

The connector provides robust mechanical and environmental protection with its chrome plated brass housing and an IP67 rating, ensuring performance in water and dust exposed environments.

Its push-pull mating design offers secure and easy connections, reducing the risk of accidental disconnections typically encountered in industrial settings. The product operates safely up to 250 volts and carries currents up to 13 amps, making it suitable for power and signal applications alike.

Operating over a wide temperature range from -40°C to 85°C, this connector can be deployed in various climatic and industrial conditions.

The solder termination provides a reliable electrical and mechanical connection to cables with outer diameters between 5 and 8 mm. The panel hole cutout diameter required for mounting is 12 mm.

This connector is ideally suited for use in industrial automation, manufacturing machinery, instrumentation, and environmental control systems where rugged and secure connections are essential.

Designed for industrial applications requiring reliable push-pull mating connections. Features copper contacts with gold plating to ensure optimal conductivity and corrosion resistance. Housing constructed from chrome plated brass for durable mechanical protection.

Operates at up to 250 volts and supports a current rating of 13 amps. Meets operating temperature range from -40°C to 85°C for varied thermal conditions. Connector style is straight orientation, solder termination type for secure cabling.

Certified as IP67 rated, offering dust-tight and waterproof protection. Compatible with cable outer diameters ranging from 5 mm to 8 mm. Panel hole cutout diameter required is 12 mm. Suitable for use in harsh industrial, manufacturing, and automation environments.
