ABB ComPact Home Miniature Circuit Breaker 3-Pole 6A Type B 440V AC 6 kA Breaking Capacity SH200
Specifications
| Country of Origin | Germany |
|---|---|
| Range | ComPact Home |
| Brand | ABB |
| Height | 85mm |
| Model | SH200 |
| Depth | 69mm |
| IP Rating | IP20 |
| Width | 52.5mm |
| Mount Type | DIN Rail |
| Current Rating | 6A |
| Series | SH200 |
| Terminal type | Screw Clamp |
| Breaking Capacity | 6kA |
| Number of Poles | 3 |
| Standards/Approvals | IEC/EN 60898-1 |
| Rated AC Voltage | 440V ac |
| Tripping Characteristics | Type B |
| Better World Claim | Designed for Disassembly |
| Tripping Mechanism | Electromechanic, Thermal |
| Reset Actuator Type | Toggle Switch |
Key Features
- Features a current rating of 6A with Type B tripping characteristics.
- Compact 3-pole design suitable for DIN Rail mounting.
- Equipped with a screw clamp terminal and toggle switch reset actuator.
- Complies with IEC/EN 60898-1 standards for safety and reliability.
- Has an IP20 rating ensuring protection against solid foreign objects.
- Constructed to operate within temperatures from -25°C to +55°C.
- Designed for straightforward disassembly, enhancing maintenance and recycling.
- Bright yellow toggle switch for easy manual operation and reset.
Product Description
It offers a breaking capacity of 6 kA at 440V AC, ensuring reliable protection for electrical circuits against overloads and short circuits in residential, commercial, and industrial electrical installations.
This miniature circuit breaker features a current-limiting design to enhance system safety and stability by reducing fault energy. It is designed for DIN Rail mounting with screw clamp terminals ensuring secure connections. The toggle switch actuator provides intuitive manual control for on/off operations.
Compliant with international IEC/EN 60898-1 standards and BS EN 60898, this device meets rigorous safety and performance criteria. Its IP20 rating protects against solid objects greater than 12 mm, suitable for indoor electrical panels.
The device is built to operate reliably within an ambient temperature range of -25°C to +55°C, making it adaptable for various environmental conditions. Moreover, it is designed for easy disassembly which supports maintenance and environmental sustainability through recyclability.
Applications include residential electrical panels, commercial installations, protection of industrial machinery and automation systems, as well as electrical systems in solar inverters. The compact dimensions (85mm height, 52.5mm width, and 69mm depth) facilitate space-saving integration into electrical distribution boards.
Current-limiting design enhances electrical safety and system stability. Type B tripping curve for versatile application suitability. Suitable for protecting residential, commercial, and industrial circuits. DIN Rail mounting with screw clamp terminal ensures secure installation.
Complies with IEC/EN 60898-1 and BS EN 60898 standards for assured quality. IP20 rating safeguards against ingress of solid foreign bodies. Works reliably from -25°C up to +55°C operating temperature. Toggle switch actuator enables easy manual operation and reset.
Designed for disassembly to ease maintenance and recycling efforts. Discover more products within Miniature Circuit Breakers and Circuit Breakers categories on EnvMart to meet your electrical protection needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
It has a breaking capacity of 6 kA at 440V AC, providing reliable protection against overloads and short circuits.
The dimensions are 85mm in height, 52.5mm in width, and 69mm in depth, allowing for space-saving integration into electrical distribution boards.
This unit is designed for DIN Rail mounting, ensuring secure installation in electrical panels.
It features a current rating of 6A, suitable for various electrical applications.
It has Type B tripping characteristics, making it versatile for different applications in residential and commercial settings.
The circuit breaker has an IP20 rating, which protects against solid foreign objects greater than 12 mm, suitable for indoor use.
It operates reliably within an ambient temperature range of -25°C to +55°C, making it adaptable to various environmental conditions.
It is equipped with screw clamp terminals, ensuring secure connections during installation.
It complies with IEC/EN 60898-1 and BS EN 60898 standards, ensuring safety and performance criteria are met.
It features a toggle switch actuator for intuitive manual control and easy reset operations.
The product is manufactured in Germany, adhering to high standards of quality and safety.
It is suitable for protecting residential electrical panels, commercial installations, and industrial machinery, among other applications.
