EAO Illuminated Push Button Switch Panel Mount Momentary SPDT Red LED 22.3 mm Cutout IP65 IP67 240 V dc 82-6151.1114



Category Push Button Switch Brand EAO Condition New

Specifications

Country of Origin	Switzerland
Brand	EAO
Length	34.5mm
IP Rating	IP65, IP67
Mount Type	Panel
Series	82
Maximum Operating Temperature	70°C
Contact Configuration	SPDT
Switch Configuration	Snap Action
Minimum Operating Temperature	-30°C
Panel Cutout Size	22.3 mm
Standards/Approvals	CB, CCC, cUL, UL
LED Colour	Red
Switch Operation	Momentary
Actuator Colour	Silver
Contact DC Voltage	240V dc
Actuator Style	Round
Switch Contact Current	3A
Contact AC Voltage	240V ac

Key Features

Constructed with stainless steel for durability and corrosion resistance.
Designed for 22.3 mm diameter panel cutout with a compact 34.5 mm length.
Features momentary snap-action switch operation suitable for short-term machine controls.
Provides SPDT contact configuration for versatile dual circuit control.
Incorporates red LED illumination for clear visibility in low-light environments.
Rated to IP65 and IP67 standards for water and dust ingress protection.
Operates reliably within a temperature range of -30°C to +70°C.
Supports contact voltages up to 240 V AC/DC and contact current up to 3 A.

Product Description

EAO 82-6151.1114 Illuminated Push Button Switch is a high-quality momentary switch designed for panel mounting in industrial automation and electrical control applications. It features a compact 22.3 mm cutout size and a stainless steel actuator in silver color, ensuring impact resistance and corrosion durability. The switch is equipped with a red LED for easy visual identification even in low-light conditions.

The SPDT contact configuration allows simultaneous control of two circuits, enhancing operational flexibility. It operates within a robust temperature range from -30°C to +70°C and is rated IP65 and IP67, guaranteeing protection against dust ingress and submersion in water up to 1 meter for 30 minutes. The momentary snap-action mechanism provides reliable short-term machine control, ideal for applications such as roller doors, lifts, factory machinery, vending machines, and production lines.

The device complies with international standards including CB, CCC, cUL, and UL, assuring safety and performance. Its length of 34.5 mm and minimal panel protrusion of 2 mm optimize installation in control panels without risk of accidental activation.

The push button’s design and protective ratings make it perfectly suited for demanding industrial, manufacturing, and commercial environments that require dependable manual control switches. Its durable construction and LED illumination contribute to long-lasting performance exceeding one million mechanical cycles.

Constructed from stainless steel for durability and corrosion resistance. 22.3 mm panel cutout size ensures compact installation. Momentary snap-action switch providing reliable short-term control. SPDT contact configuration supports control of two circuits simultaneously.

Red LED illumination for easy visibility in low light. IP65 and IP67 ratings protect against dust and temporary water immersion. Operating temperature range from -30°C to +70°C supports diverse environments. Supports contact voltages of 240 V AC/DC and 3 A contact current.

Minimal 2 mm panel protrusion reduces accidental activation risk.

Choose the EAO 82 Series Illuminated Push Button Switch for robust, clear, and reliable industrial manual control functionality. Browse more switches and industrial control components on EnvMart.
