Texas Instruments Comparator Low Power Push Pull Output 3 V to 5.5 V, 75 ns Response Time, 5-Pin SOT-23 LMV7239M5/NOPB

Free Delivery in India | Lowest Global Shipping Charges

Texas Instruments Comparator Low Power Push Pull Output 3 V to 5.5 V, 75 ns Response Time, 5-Pin SOT-23 LMV7239M5/NOPB

Name: Texas Instruments Comparator Low Power Push Pull Output 3 V to 5.5 V, 75 ns Response Time, 5-Pin SOT-23 LMV7239M5/NOPB
Brand: Texas Instruments
SKU: 195356
Price: 2.8 USD
Availability: InStock



Category Amplifiers & Comparators Brand Texas Instruments Condition New

Specifications

Country of Origin	India
Brand	Texas Instruments
Height	1.02mm
Length	2.92mm
Model	LMV7239M5/NOPB
Width	1.6mm
Mount Type	Surface
Output type	Push Pull
Maximum Operating Temperature	85°C
Package Type	SOT-23
Minimum Operating Temperature	-40°C
Number Of Channels	1
Comparator Type	Low Power
Pin Count	5
Maximum Supply Voltage	5.5V
Minimum Supply Voltage	3V
Supply Current	110μA
Typical Response Time	75ns

Key Features

Operates with a minimum supply voltage of 3 V and maximum of 5.5 V.
Comes in a compact 5-pin SOT-23 surface mount package.
Typical response time is 75 nanoseconds for rapid switching applications.
Consists of a single comparator channel with push-pull output type.
Supply current is exceptionally low at just 110 μA.
Designed to operate in temperature range from -40°C to 85°C.
Ideal for applications requiring low voltage, low power consumption, and fast comparator switching.
This comparator is well suited for electronics and semiconductor projects focusing on precise voltage comparison.

Product Description

Texas Instruments LMV7239M5/NOPB low power comparator features a push-pull output with a fast 75 nanosecond typical response time, operating on supply voltages ranging from 3 V to 5.5 V. It is encapsulated in a standard 5-pin SOT-23 surface mount package, measuring 2.92 mm in length, 1.6 mm in width, and 1.02 mm in height, making it compact and suitable for space-constrained industrial and electronics applications.

The device contains a single comparator channel optimized for low power consumption, drawing just 110 μA typical supply current, ideal for battery-powered and energy-conscious designs. It supports a wide operating temperature range from -40°C to 85°C, ensuring reliability in diverse environments, including industrial, automotive (non-automotive standard), and consumer electronics.

Unlike operational amplifiers intended for linear feedback systems, this comparator is designed specifically for rapid switching and makes use of a push-pull output stage for faster transitions without open-collector limitations. This makes it excellent for use in semiconductor circuits requiring fast and accurate voltage threshold detections.

This product is commonly used in industrial electronics, semiconductor devices, power management systems, and embedded control schemes where quick and precise voltage comparison is essential. Its SOT-23 package allows easy PCB integration with surface mount assembly techniques.

Low power consumption at 110 μA supply current. Push-pull output eliminates need for external pull-up resistor. Fast 75 ns response time suitable for high-speed applications. Wide supply voltage range between 3 V and 5.5 V.

Compact 5-pin SOT-23 package for space saving. Explore EnvMart's selection of semiconductor comparators for enhanced use in electronic design, power management solutions, and embedded systems engineering.
