Amphenol Industrial SURLOK PLUS RADSOK EV Connector Female, 300A, Panel Mount, 70mm² Wire SLPIRC70CPSB0 / C10-730191-1700
Specifications
| Country of Origin | China |
|---|---|
| Brand | Amphenol Industrial |
| Colour | Black |
| Orientation | Straight |
| Current | 300A |
| Height | 35mm |
| Model | SLPIRC70CPSB0 / C10-730191-1700 |
| Depth | 69.2mm |
| IP Rating | IP67 |
| Connector Type | RADSOK |
| Width | 35mm |
| Mount Type | Panel Mount |
| Housing Material | Thermoplastic |
| Contact Material | Copper Alloy |
| Series | SURLOK PLUS |
| Termination Type | Crimp |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -40°C |
| Pin Diameter | 10.3mm |
| Number of Rows | 1 |
| Wire size | 70mm² |
| Operating Voltage | 1000V |
| For Use With | SurLok 1-Position Plug |
| Standards/Approvals | UL 94-V0 |
| Number of Contacts | 1 |
| Contact Gender | Male |
| Connector Gender | Female |
| Better World Claim | Renewable Energy Solution |
Key Features
- The connector is part of the SURLOK PLUS series designed for Electric Vehicle and heavy equipment use.
- Rated for 1000V operating voltage and supports 70mm² wire size with crimp termination.
- Features IP67 ingress protection and UL 94-V0 flammability rating for superior durability.
- Operating temperature range from -40°C to 125°C ensures reliable performance in harsh environments.
- Constructed with copper alloy contacts and thermoplastic housing for enhanced conductivity and insulation.
- Designed with spring locking and a keyed 90-degree orientation to prevent mismating.
- Compact dimensions of 35mm width, 35mm height, and 69.2mm depth facilitate panel mount integration.
- Offers touch-proof design and uses RADSOK technology for a high tensile strength and conductive connection.
Product Description
Amphenol Industrial SLPIRC70CPSB0 / C10-730191-1700 is a high-performance SURLOK PLUS RADSOK EV Connector Female rated at 300A and designed for panel mount applications.
Its durable construction features a thermoplastic housing with copper alloy contacts, delivering reliable electrical performance. The connector supports 70mm² wire size and terminates via crimping, ensuring secure and efficient connections in demanding environments.
This connector is engineered to operate across a wide temperature range of -40°C to 125°C and withstands high operating voltages up to 1000V. Its IP67 rating guarantees protection against dust and water ingress, making it suitable for harsh industrial and automotive conditions.
The SURLOK PLUS series incorporates RADSOK technology which provides a robust, high tensile strength connection with increased conductive surface area. The design includes a 10.3mm diameter pin, keyed at 90 degrees, to prevent misalignment and enhance safety with a touch-proof interface and spring locking mechanism.
Typical applications cover electric vehicles (EV/HEV), rail mass transit systems, battery management systems, process control, and medical equipment, reflecting its versatile industrial utility.
The connector is touch-proof and key-coded for precise mating. Spring locking mechanism ensures a secure and stable connection. Meets UL 94-V0 flammability standards for safety compliance. Panel mount design simplifies integration into enclosures and control panels.
IP67 rating provides outstanding environmental sealing.
Originating from China, this Amphenol Industrial connector embodies quality and reliability, making it an essential component for electrical connectivity in critical industrial and automotive applications.
Explore a broad range of EV connectors and power Connectors at EnvMart to support your industrial and commercial electrical needs.
