Amphenol Industrial SURLOK PLUS RADSOK EV Connector Female 200A 1000V Panel Mount IP67 SLPRB50CPSB / C10-730189-100
Specifications
| Country of Origin | China |
|---|---|
| Brand | Amphenol Industrial |
| Colour | Black |
| Orientation | Straight |
| Current | 200A |
| Height | 30mm |
| Model | SLPRB50CPSB / C10-730189-100 |
| Depth | 53.7mm |
| IP Rating | IP67 |
| Connector Type | RADSOK |
| Width | 30mm |
| Mount Type | Panel Mount |
| Housing Material | Thermoplastic |
| Contact Material | Copper Alloy |
| Series | SURLOK PLUS |
| Termination Type | Crimp |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -40°C |
| Pin Diameter | 8mm |
| Number of Rows | 1 |
| Wire size | 50mm² |
| Operating Voltage | 1000V |
| For Use With | SurLok 1-Position Plug |
| Standards/Approvals | UL 94-V0 |
| Number of Contacts | 1 |
| Contact Gender | Male |
| Connector Gender | Female |
| Better World Claim | Renewable Energy Solution |
Key Features
- Features a RADSOK connector type with 1 row and 1 contact for reliable electrical connection.
- Suitable for wire size of 50mm² with an 8mm pin diameter for enhanced conductivity.
- Operates within a temperature range from -40°C to 125°C ensuring durability under harsh environments.
- Designed with spring locking and touch proof technology for safety and secure connections.
- IP67 rated for dust and water resistance ideal for industrial and electric vehicle applications.
- Constructed with copper alloy contacts and thermoplastic housing for longevity and flame resistance.
- Meets UL 94-V0 flammability standard suitable for high safety requirements.
- Keyed design prevents mismating and ensures correct installation every time.
Product Description
Amphenol Industrial SLPRB50CPSB / C10-730189-100 SURLOK PLUS RADSOK EV Connector Female is a high performance electrical connector rated at 200A and 1000V designed for demanding industrial and electric vehicle applications.
This connector features the RADSOK technology ensuring superior tensile strength and excellent conductive surface area for reliable power transmission. It includes one row with a single contact and an 8mm pin diameter to support a 50mm² wire size.
The component supports a wide operating temperature range from -40°C up to 125°C, ensuring consistent performance in various environments. Its panel mount flange design allows for easy integration into systems requiring robust and secure mounting.
Constructed with copper alloy contacts for high conductivity and thermoplastic housing rated UL 94-V0 for flame resistance, this connector also meets IP67 ingress protection standards making it resistant to dust and water.
Additional features include touch proof design, spring locking for secure connections, and a keyed mechanism to prevent improper mating. These attributes make it suitable for industrial, rail mass transit, battery management, process control, medical, and heavy equipment applications.
Features a RADSOK connector type with 1 row and 1 contact for reliable electrical connection. Suitable for wire size of 50mm² with an 8mm pin diameter for enhanced conductivity. Operates within a temperature range from -40°C to 125°C ensuring durability under harsh environments.
Designed with spring locking and touch proof technology for safety and secure connections. IP67 rated for dust and water resistance ideal for industrial and electric vehicle applications. Constructed with copper alloy contacts and thermoplastic housing for longevity and flame resistance.
Meets UL 94-V0 flammability standard suitable for high safety requirements. Keyed design prevents mismating and ensures correct installation every time. Panel mount flange allows easy and stable installation in various setups.
Complies with better world claim of renewable energy solution supporting sustainable product use.
This product supports sustainable and renewable energy solutions aligning with modern environmental standards. It is an essential component for EV/HEV systems, rail mass transit, process control, battery management systems, medical, and heavy equipment industries.
Discover the Amphenol Industrial range of SURLOK PLUS EV Connectors for reliable, safe, and efficient power connections in your industrial and automotive applications.
