Lumileds 3.5 V Blue LED 3535 Surface Mount LUXEON 3535L L135-B475003500000

The Lumileds L135-B475003500000 is a high performance blue LED from the LUXEON 3535L series featuring a standard 3535 footprint for easy integration into existing designs. This LED operates at a forward voltage of 3.5 volts with a maximum forward current of 200 mA, providing efficient light output with a luminous flux of 11 lumens.

It features a surface mount package type with a dimension of 3.7 x 3.5 x 0.8 millimeters, and a round diffused lens that provides a wide viewing angle of 115 degrees, optimized for uniform light distribution.

The dominant wavelength of 480 nanometers emits a vibrant blue light suitable for various indoor and outdoor illumination needs. Compliant with RoHS standards, this LED ensures environmentally responsible manufacturing and safety.

3.5 V forward voltage with 200 mA maximum current rating. Compact 3535 surface mount package for streamlined assembly. Blue light emission at 480 nm wavelength with 11 lm flux. Wide viewing angle of 115° for broad illumination.

Diffused, colourless lens shape designed for consistent light output. Packaged in tape & reel, enabling efficient automated production. Applications include architectural lighting, downlights, indoor area lighting, lamps, and outdoor lighting.

These attributes make the Lumileds L135-B475003500000 an ideal component for sustainable and high efficacy lighting designs in industrial, commercial, and residential contexts. Explore the full range of Lumileds LED technology in the electronics components category on EnvMart for reliable lighting solutions.
