RS PRO Right Angle Through Hole Pin Header, 36 Contacts, 2.54 mm Pitch, 1 Row, Unshrouded 251-8446

RS PRO 251-8446 is a Right Angle Through Hole Pin Header designed for precise PCB connector applications. Featuring 36 contacts arranged in a single row with 2.54 mm pitch, this unshrouded header supports varied industrial and electronic manufacturing uses, including embedded systems and custom PCB assemblies.

The housing is made from durable polybutylene terephthalate, providing excellent insulation and mechanical stability. Brass contacts with tin plating enhance electrical conductivity and resistance to corrosion. The through-hole mount with solder termination ensures a robust and permanent fixture to the PCB, suitable for both prototyping and production runs.

Electrical specifications include a maximum current rating of 1 Amp and operating voltage up to 650 V, suitable for low to medium power electronic circuits. The header operates reliably across temperatures ranging from -65°C to 150°C, highlighting its suitability for diverse environmental conditions.

This connector's right angle orientation enables compact PCB layouts where vertical space is constrained. The tail pin length of 5.84 mm and mating pin length of 9.7 mm are optimized for secure solder joints and reliable mating with connectors or sockets. The unshrouded design facilitates easy inspection and soldering during assembly processes.

Compliance with RoHS standards ensures this component meets current environmental regulations, making it suitable for eco-conscious manufacturing. The header is manufactured in Taiwan, Province of China, assuring consistent quality and reliability.

This pin header includes 36 individual contacts in a single row with 2.54 mm spacing. Right angle orientation allows versatile PCB mounting options. Durable polybutylene terephthalate housing provides insulation and strength.

Brass contacts are tin plated to prevent corrosion and improve conductivity. Through-hole solder termination ensures strong mechanical and electrical connections. Rated for 1 Amp current and 650 Volt voltage for industrial and electronic applications.

Operating temperature range spans from -65°C to 150°C for harsh environments. Tail pin and mating pin lengths support reliable connector mating and soldering. Unshrouded design for easy access during assembly and maintenance.

RoHS compliant for environmentally responsible manufacturing. Manufactured with precision in Taiwan, Province Of China.

This RS PRO Right Angle Through Hole Pin Header is ideal for electronics manufacturing, prototyping, industrial automation, and embedded systems. It offers dependable electrical connections in compact PCB layouts, sustaining performance under varied environmental conditions. Explore this high-quality PCB header and similar RS PRO connectors on EnvMart for your electronic component needs.
