Eurotherm Panel Mount PID Controller 1 Input 1 Relay Logic SSR 24V AC/DC, LCD Display EPC3016

Eurotherm EPC3016 is a panel mount programmable PID controller designed for precise and repeatable single-loop temperature control in industrial processes. This model features one input compatible with current, thermocouple, and voltage signals, and one relay output supporting Logic/SSR 24V AC/DC, making it suitable for various automation applications.

The controller integrates a high-speed native Ethernet interface with RJ45 connector, enabling seamless connection to Industry 4.0 and Industrial Internet of Things (IIoT) systems. It complies with RoHS standards and is designed to operate reliably within 0 to 55°C ambient temperature while protecting against dust and water with an IP65 rating.

With a clear LCD display, the EPC3016 ensures easy operation and parameter monitoring. It offers enhanced Eurotherm PID control algorithms with a cutback function to guarantee fast response times and minimal temperature overshoot, crucial in precision temperature regulation environments such as aerospace processes adhering to AMS2750 and CQI 9 standards.

Additional features include wireable function blocks for math, logic, and advanced controls, and support for communication protocols like Modbus, Ethernet/IP, and BACnet. The device includes options certified by Factory Mutual for temperature limit control, increasing industrial safety compliance. Its compact panel mount design offers dimensions of 48mm width, 101mm length, and 90mm depth, making it suitable for space-constrained installations.

One input compatible with current, thermocouple, and voltage signals. One relay output with Logic/SSR 24V AC/DC capability. High-speed native Ethernet interface with RJ45 connector supporting IIoT. Compliance with RoHS standards.

IP65 rated for protection against dust and moisture. Enhanced PID control with cutback function for accurate temperature regulation. Supports multiple communication protocols including Modbus and BACnet. Factory Mutual approved temperature limit option available.

Compact panel mount design for industrial installation. Operates within temperature limits of 0 to 55°C.

This Eurotherm EPC3016 PID controller is ideal for optimizing production yields in thermal and other processing industries. It is well-suited for industrial automation, HVAC, manufacturing process control, and laboratory use requiring precise temperature management. Discover more products in our Temperature Controllers category at EnvMart.
