Siemens Inverter Drive 4 kW 3 Phase SINAMICS G115D Series 6SL3520-1XD04-0AF0 480V 20.4 A
Specifications
| Country of Origin | United Kingdom |
|---|---|
| Brand | Siemens |
| Model | 6SL3520-1XD04-0AF0 |
| IP Rating | IP66, IP65 |
| Mount Type | Wall |
| Overall Length | 180mm |
| Series | SINAMICS G115D |
| Overall Width | 425mm |
| Power Rating | 4kW |
| Maximum Operating Temperature | 55°C |
| Output Frequency | 550Hz |
| Minimum Operating Temperature | -30°C |
| Interfaces | Ethernet/IP communication |
| Number of Phases | 3 |
| Maximum Output Current | 20.4A |
| Standards/Approvals | CE, KCC, EAC, cUL, C-Tick (RCM), UL, SEMI F47, REACH |
| Maximum Supply Voltage | 480V |
| Overall Depth | 169mm |
| Minimum Supply Voltage | 380V |
| Better World Claim | Saves Energy |
| Compatible Motor Type | AC Motor |
Key Features
- Wall-mounted distributed inverter drive system suitable for intralogistics and airport industries.
- Supports 3 phase asynchronous motors with efficiency class up to IE3 and synchronous reluctance motors up to IE4.
- Provides rated power output of 4 kW with maximum output current of 20.4 A.
- Equipped with PROFINET, Ethernet/IP communications and integrated RFI suppression filter for category C2.
- Designed for operating temperatures ranging from -30°C to 55°C with IP66 and IP65 ingress protection rating.
- Compact form factor with dimensions 425 mm width, 180 mm length, and 169 mm depth.
- Compliant with multiple standards including CE, KCC, EAC, cUL, C-Tick (RCM), UL, SEMI F47, and REACH.
Product Description
Siemens 6SL3520-1XD04-0AF0 Inverter Drive 4 kW 3 Phase SINAMICS G115D Series 480V 20.4 A is a robust, wall-mounted distributed drive designed for continuous motion applications primarily in conveyor technology. It is ideal for industries such as intralogistics, airports, automotive manufacturing, and food, beverage, and packaging where simple horizontal motion control is required.
This 3 phase AC inverter drive supports three-phase asynchronous motors with efficiency classes up to IE3 as well as high-efficiency synchronous reluctance motors with class IE4. It delivers a rated power of 4 kW and a maximum output current of 20.4 A, ensuring efficient power delivery and reliable performance.
The drive includes a modular concept with a fully preconfigured converter integrating plug-in connections without daisy chaining, supporting PROFINET and Ethernet/IP communication protocols for seamless network integration. An integrated RFI suppression filter category C2 reduces electromagnetic interference, enhancing system reliability.
Designed for harsh environments, it complies with IP66 and IP65 ingress protection ratings, suitable for dusty and wet conditions. The drive can operate efficiently within a temperature range of -30°C to 55°C. Compact dimensions of 425 mm width, 180 mm length, and 169 mm depth enable installation in constrained spaces.
Manufactured to high standards, it meets certifications including CE, KCC, EAC, cUL, C-Tick (RCM), UL, SEMI F47, and REACH, ensuring safety and regulatory compliance. This product contributes to energy savings and sustainability goals in industrial automation.
Wall-mounted distributed inverter drive for conveyor technology and industrial applications. Supports asynchronous and synchronous reluctance motors with IE3 and IE4 efficiency classes. Rated power of 4 kW and max output current of 20.4 A.
PROFINET and Ethernet/IP communications with plug-in connector system. Integrated RFI suppression filter for category C2. IP66 and IP65 rated for harsh operating environments. Operating temperature range: -30°C to 55°C. Compact size with dimensions 425x180x169 mm.
Certified with CE, KCC, EAC, UL and other international standards. Ideal for intralogistics, airport, automotive, food and packaging industries. Explore more Siemens automation and Inverter Drives on EnvMart for high-quality industrial solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The Siemens inverter drive has a power rating of 4 kW.
This model has a maximum output current of 20.4 A.
It supports three-phase asynchronous motors with efficiency classes up to IE3 and synchronous reluctance motors up to IE4.
The inverter drive operates efficiently within a temperature range of -30°C to 55°C.
It has an IP66 and IP65 ingress protection rating, suitable for dusty and wet conditions.
This unit is equipped with Ethernet/IP communication capabilities.
The dimensions are 425 mm in width, 180 mm in length, and 169 mm in depth.
The minimum supply voltage is 380V, and the maximum supply voltage is 480V.
It complies with several standards including CE, KCC, EAC, cUL, C-Tick (RCM), UL, SEMI F47, and REACH.
It is designed for wall mounting.
The output frequency of this model is 550 Hz.
It is ideal for industries such as intralogistics, airports, automotive manufacturing, and food and beverage packaging.
