Siemens Inverter Drive SINAMICS G115D Series 4 kW 3 Phase 480V 20.4 A 6SL3520-2XE44-0AB0
Specifications
| Country of Origin | United Kingdom |
|---|---|
| Brand | Siemens |
| Model | 6SL3520-2XE44-0AB0 |
| IP Rating | IP66, IP65 |
| Mount Type | Wall |
| Overall Length | 180mm |
| Series | SINAMICS G115D |
| Overall Width | 425mm |
| Power Rating | 4kW |
| Maximum Operating Temperature | 55°C |
| Output Frequency | 550Hz |
| Minimum Operating Temperature | -30°C |
| Number of Phases | 3 |
| Maximum Output Current | 20.4A |
| Standards/Approvals | REACH, RCM (C-Tick), Low Voltage Directive 2014/35/EC, KCC, EMC Directive 2014/30/EC, EAC, cUL, CE, RoHS, WEEE Directive, UL, SEMI F47 |
| Maximum Supply Voltage | 480V |
| Overall Depth | 169mm |
| Minimum Supply Voltage | 380V |
| Better World Claim | Saves Energy |
| Compatible Motor Type | 3 Phase AC Motors |
Key Features
- Wall mount type with compact dimensions for space-efficient installation.
- Operating temperature range from -30°C to 55°C ensuring reliability in harsh environments.
- IP65 and IP66 rated for superior ingress protection against dust and water.
- Provides sensorless vector control and encoderless torque control for efficient motor operation.
- Equipped with RFI suppression filter conforming to Category C2 standards.
- Air-cooled by an integrated fan ensuring optimal thermal management.
- Compatible with 3 phase AC motors supporting various industrial configurations.
- Supports output frequencies up to 550 Hz for versatile motor speed control.
Product Description
Siemens 6SL3520-2XE44-0AB0 inverter drive, part of the SINAMICS G115D Series, delivers 4 kW power at 3 phase 480V voltage and maximum output current of 20.4 A. This wall-mounted distributed drive system features FSB frame size and is designed for efficiency and sustainability in electrical motor applications.
It operates reliably within a temperature range of -30°C to 55°C and has an overall compact form factor with dimensions of 425 mm width, 180 mm length, and 169 mm depth. The device is IP65/IP66 rated, providing robust protection against dust and water ingress, suitable for challenging industrial environments.
The inverter drive offers sensorless vector control and encoderless torque control, enhancing motor performance without requiring additional sensors. With a maximum output frequency of 550 Hz and compatible with 3 phase AC motors, it enables precise speed and torque control across various industrial sectors such as manufacturing, HVAC, automation, and water treatment.
Additional features include an integrated RFI suppression filter meeting Category C2 requirements, and it is air cooled by an integrated fan to maintain optimal operating temperature and reliability during prolonged use. The drive supports supply voltages between 380V and 480V, making it adaptable to diverse power systems.
Manufactured in the United Kingdom, this inverter drive complies with international standards including REACH, RCM (C-Tick), Low Voltage Directive 2014/35/EC, EMC Directive 2014/30/EC, CE, UL, RoHS, WEEE Directive, KCC, EAC, and SEMI F47. It is a Better World product designed to save energy and reduce carbon footprint, supporting sustainability goals in industrial operations.
Wall mount type with compact dimensions for space-efficient installation. Operating temperature range from -30°C to 55°C ensuring reliability in harsh environments. IP65 and IP66 rated for superior ingress protection against dust and water.
Provides sensorless vector control and encoderless torque control for efficient motor operation. Equipped with RFI suppression filter conforming to Category C2 standards. Air-cooled by an integrated fan ensuring optimal thermal management.
Compatible with 3 phase AC motors supporting various industrial configurations. Supports output frequencies up to 550 Hz for versatile motor speed control. Manufactured in the United Kingdom ensuring high quality and durability.
Explore the Siemens inverter drive range and related automation products on EnvMart to meet your industrial automation and motor control requirements.
Explore more products in our Inverter Drives category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The Siemens inverter drive has a power rating of 4 kW.
This model has a maximum output current of 20.4 A.
It operates reliably within a temperature range of -30°C to 55°C.
The inverter drive is rated IP65 and IP66, providing protection against dust and water ingress.
It is compatible with 3 phase AC motors.
The maximum output frequency supported is 550 Hz.
It is air-cooled by an integrated fan to maintain optimal thermal management.
The dimensions are 425 mm in width, 180 mm in length, and 169 mm in depth.
It complies with several standards including REACH, CE, UL, RoHS, and others.
It is designed for wall mounting, allowing for space-efficient installation.
This inverter drive is manufactured in the United Kingdom.
It is designed to save energy, supporting sustainability goals in industrial operations.
