Siemens Inverter Drive, 4 kW Power Rating, 3 Phase, SINAMICS G115D Series, 480V, 20.4 A, Wall Mount 6SL3520-0XH64-0AB0

Siemens 6SL3520-0XH64-0AB0 Inverter Drive is a high-performance 4 kW power device from the SINAMICS G115D series designed for three phase industrial power supply and control applications. The wall mount unit supports industry standards and provides advanced functionality suitable for manufacturing and automation systems.

This inverter drive features compatibility with SIMOGEAR 2KJ8 geared motors and asynchronous three-phase AC motors with efficiency classes IE3 and IE4 synchronous reluctance motors. It is engineered to satisfy the comprehensive requirements of horizontal conveyor systems ranging from simple speed control to sophisticated encoderless vector control techniques, providing versatility and enhanced motor performance.

The device comes with integrated safety features including STO (Safe Torque Off) function with fail-safe digital input (F-DI) or PROFIsafe support ensuring operator safety during operation. The compact design removes the need for a separate control cabinet, saving installation space and reducing cooling requirements.

Durability is enhanced with IP65 and IP66 ingress protection ratings, allowing it to operate reliably in harsh industrial environments. Operating temperature ranges from -30°C to 55°C ensure broad environmental adaptability.

Dimensions of 425 mm width, 240 mm length, and 169 mm depth enable easy integration into existing setups. Certified to international standards including CE, cUL, UL, C-Tick (RCM), SEMI F47, EAC, KCC, and REACH compliance ensures global eligibility for use.

Robust 4 kW power output with compatible three-phase configuration. Maximum output current capacity of 20.4 A suitable for demanding industrial loads. Wall mount type for streamlined installation and maintenance access. High ingress protection ratings IP65 and IP66 for dust and water resistance.

Wide operating temperature range of -30°C to 55°C for diverse environments. Integrated safety functions including STO and fail-safe digital inputs. Supports high frequency output up to 550 Hz for precision motor control.

Compatible with IE3 asynchronous and IE4 synchronous reluctance AC motors. Compact dimensions facilitating integration in constrained spaces. Conforms to multiple global safety and environmental standards.

This Siemens inverter drive is ideally suited for use in industrial automation, manufacturing lines, conveyor systems, HVAC systems, and other commercial applications requiring reliable motor speed and torque control.
