ABB System Pro M Compact S200 Miniature Circuit Breaker 3+N-Pole 1A Type C 400V ac 12V dc 6kA Breaking 2CDS253103R0014

Free Delivery in India | Lowest Global Shipping Charges

ABB System Pro M Compact S200 Miniature Circuit Breaker 3+N-Pole 1A Type C 400V ac 12V dc 6kA Breaking 2CDS253103R0014



Category Miniature Circuit Breaker Brand ABB Condition New

Specifications

Country of Origin	Germany
Range	System Pro M Compact
Brand	ABB
Height	88mm
Model	2CDS253103R0014
Depth	69mm
IP Rating	IP20
Width	70mm
Mount Type	DIN Rail
Current Rating	1A
Series	S200
Terminal type	Screw
Breaking Capacity	6kA
Number of Poles	3+N
Standards/Approvals	IEC/EN 60898-1, IEC/EN 60947-2, UL1077
Rated AC Voltage	400V ac
Rated DC Voltage	12V dc
Tripping Characteristics	Type C
Better World Claim	Designed for Disassembly
Tripping Mechanism	Thermal, Electromechanic

Key Features

Rated for 400V ac and 12V dc operation with a breaking capacity of 6 kA.
Features a thermal and electromechanic tripping mechanism for reliable overload and short circuit protection.
Designed to mount on DIN rail with screw terminal type connections for secure installation.
Constructed with IP20 protection rating and compliant with IEC/EN 60898-1, IEC/EN 60947-2, and UL1077 standards.
Compact dimensions of 88mm height, 70mm width, and 69mm depth suit modern electrical panels.
Designed for disassembly as part of ABB’s Better World sustainability initiative.
Operates reliably in ambient temperatures from -25 to +55 °C.

Product Description

ABB 2CDS253103R0014 System Pro M Compact S200 Miniature Circuit Breaker is a precision-engineered device designed for the protection of electrical circuits in industrial, commercial, and residential applications. Rated at 1 ampere current and featuring a 3+N pole configuration, this breaker provides efficient control and safe interruption of current.

The breaker supports a rated AC voltage of 400V and a DC voltage rating of 12V, with a breaking capacity of 6 kiloamperes ensuring robust protection against short circuits and overload events. This MCB utilizes dual tripping mechanisms: a thermal trip for overload conditions and an electromechanic trip for short circuits, enhancing reliability.

It is built to be mounted conveniently on DIN rails and includes screw-type terminals for secure wiring. Its IP20 ingress protection rating makes it suitable for indoor panel usage, protecting against solid particle intrusion. The product complies with industry standards IEC/EN 60898-1, IEC/EN 60947-2, and UL1077, assuring quality and safety.

The compact size of 88mm in height, 70mm in width, and 69mm in depth allows integration into varied electrical setups without occupying excessive space. Additionally, this breaker is part of ABB’s Better World initiative, designed for easy disassembly to facilitate recycling and sustainability.

Suitable for ambient operating temperatures ranging from -25 to +55 degrees Celsius, it is ideal for diverse environmental conditions in industrial, manufacturing, and commercial electrical distribution systems.

Rated for 400V ac and 12V dc operation with 6 kA breaking capacity. Dual thermal and electromechanic trip mechanisms ensure enhanced protection. DIN rail mount with screw terminals for secure installation. Meets IEC/EN and UL safety standards.

Compact dimensions suitable for space-constrained panels. Designed for disassembly supporting sustainability goals. Operational temperature range from -25 to +55 °C.

For dependable circuit protection with proven performance, choose the ABB System Pro M Compact S200 2CDS253103R0014 Miniature Circuit Breaker. Explore more electrical protection devices and ABB products on EnvMart's platform.
