ABB Molded Case Circuit Breaker 3-Pole 160A Breaking Capacity 150 kA Fixed Mount XT2L 1SDA06 1SDA068166R1 XT2L 160 BLOC FF

Free Delivery in India | Lowest Global Shipping Charges

ABB Molded Case Circuit Breaker 3-Pole 160A Breaking Capacity 150 kA Fixed Mount XT2L 1SDA06 1SDA068166R1 XT2L 160 BLOC FF



Category MCCB Brand ABB Condition New

Specifications

Country of Origin	Italy
Range	XT2L
Brand	ABB
Height	130mm
Model	XT2L
Depth	82.5mm
Width	90mm
Mount Type	Fixed
Current Rating	160A
Series	1SDA06
Terminal type	Fixed
Breaking Capacity	150kA
Number of Poles	3
Standards/Approvals	CE, IEC, RoHS
Rated AC Voltage	690V ac
Rated DC Voltage	500V dc
Better World Claim	Designed for Disassembly
Reset Actuator Type	Lever
Short circuit performance level	L

Key Features

Rated current of 160 amperes ensures stable performance.
Three poles with fixed terminals for robust electrical connections.
Rated AC voltage of 690 volts and DC voltage of 500 volts for versatile applications.
Breaking capacity rated at 150 kA to handle high fault currents.
Complies with CE, IEC, and RoHS standards for safety and environmental considerations.
Compact dimensions with height 130 mm, width 90 mm, and depth 82.5 mm for easy installation.
Lever reset actuator type for convenient operation.
Designed for disassembly under the Better World program for sustainability.

Product Description

ABB XT2L Molded Case Circuit Breaker 3-Pole 160A, model 1SDA06 with MPN 1SDA068166R1 XT2L 160 BLOC FF, is designed for fixed mounting and provides high-performance circuit protection with a breaking capacity of 150 kA. This device is engineered to handle rated AC voltage up to 690V and DC voltage up to 500V, making it suitable for industrial, commercial, and electrical distribution applications.

The circuit breaker features a robust design with front terminals and a lever-type reset actuator for ease of use. It complies with CE, IEC, and RoHS standards, ensuring reliability, safety, and environmentally responsible manufacturing. With dimensions of 130 mm height, 90 mm width, and 82.5 mm depth, this MCCB offers a compact solution for installation in various electrical panels and systems.

The product supports electrical durability of 120 cycles per hour and a rated uninterrupted current of 160A. It includes important features for industrial performance such as short circuit performance level L and a rated insulation voltage of 1000 V (Ui). Moreover, the ABB XT2L circuit breaker is part of the Better World program and designed for disassembly to facilitate recycling and sustainability.

Rated current 160A for consistent electrical protection. Breaking capacity of 150 kA designed to withstand severe faults. Comprehensive safety standards compliance: CE, IEC, RoHS. Compact form factor for flexible mounting options in control panels.

Fixed front terminal type supports secure wiring connections. Lever actuator allows quick and safe manual resetting. Support for both AC and DC voltage systems up to 690V and 500V respectively. Short circuit performance level L ensures operational integrity under fault conditions.

Better World design for disassembly improves environmental footprint. Manufactured in Italy ensuring quality control and durability.

This molded case circuit breaker is ideal for use in industrial machinery, electrical distribution boards, automation systems, and factory electrical networks. It provides fundamental overcurrent and short circuit protection, ensuring system safety and compliance with industrial electrical codes.

Explore more ABB electrical protection devices and circuit breakers on EnvMart for a comprehensive range of reliable solutions for industrial and commercial power management.

Looking to purchase in bulk?

Purchase item in bulk quantity
Get best price for your business

Comments (0)

No customer reviews for the moment.

Frequently Asked Questions

The breaking capacity of this molded case circuit breaker is rated at 150 kA, allowing it to handle high fault currents effectively.

This model features three poles, which provides robust electrical connections for effective circuit protection.

The dimensions are 130 mm in height, 90 mm in width, and 82.5 mm in depth, allowing for easy installation in various electrical panels.

It utilizes a lever reset actuator type, which allows for convenient manual resetting of the circuit breaker.

This model complies with CE, IEC, and RoHS standards, ensuring it meets safety and environmental requirements.

The rated current for this unit is 160 amperes, ensuring stable performance in electrical applications.

It has a short circuit performance level of L, which indicates its operational integrity under fault conditions.

This product is manufactured in Italy, ensuring quality control during production.

It features fixed front terminals, which support secure wiring connections for reliable operation.

Yes, it is designed for disassembly under the Better World program, which facilitates recycling and sustainability efforts.

This molded case circuit breaker is suitable for industrial machinery, electrical distribution boards, automation systems, and factory electrical networks.
