ABB Tmax XT Molded Case Circuit Breaker 3-Pole 100A Breaking Capacity 85 kA Fixed Mount 1SDA068267R1 XT3S 250 TMG 100A FF

Free Delivery in India | Lowest Global Shipping Charges

ABB Tmax XT Molded Case Circuit Breaker 3-Pole 100A Breaking Capacity 85 kA Fixed Mount 1SDA068267R1 XT3S 250 TMG 100A FF



Category Molded Case Circuit Breaker Brand ABB Condition New

Specifications

Country of Origin	Italy
Range	Tmax XT
Brand	ABB
Height	150mm
Model	1SDA068267R1 XT3S 250 TMG 100A FF
Depth	70mm
Width	105mm
Mount Type	Fixed
Current Rating	100A
Series	Tmax XT
Terminal type	Fixed
Breaking Capacity	85kA
Number of Poles	3
Standards/Approvals	CE, IEC, RoHS
Rated AC Voltage	690V ac
Rated DC Voltage	500V dc
Better World Claim	Designed for Disassembly
Tripping Mechanism	Thermal Magnetic
Reset Actuator Type	Lever
Rated current (In)	100 A In
Rated frequency (f)	50/60 Hz
Rated voltage (Ur)	690 V
Rated impulse withstand voltage (Uimp)	8 kV

Key Features

Rated current of 100A suitable for medium power electrical distribution.
Breaking capacity of 85 kA ensures robust short circuit protection.
Fixed mounting type with front fixed terminals for secure installation.
Thermal-magnetic tripping mechanism provides both overload and short circuit protection.
Compact dimensions of 150mm height, 105mm width, and 70mm depth for space-efficient design.
Compliant with CE, IEC, and RoHS standards guaranteeing safety and environmental compliance.
Rated AC voltage of 690V and DC voltage of 500V supports a wide range of electric systems.
Reset actuator lever enables easy manual reset after tripping events.

Product Description

ABB 1SDA068267R1 XT3S 250 TMG 100A FF Molded Case Circuit Breaker 3-Pole 100A rated at 690V AC and 500V DC is engineered for high performance in industrial, commercial, and electrical automation environments. Designed with thermal magnetic tripping technology, this circuit breaker offers reliable overload and short circuit protection.

This fixed mounting breaker includes fixed front terminals ensuring secure and stable electrical connections. Its compact dimensions of 150mm height, 105mm width, and 70mm depth allow installation in tight panels or motor control centers.

With a breaking capacity of 85 kA, it can safely interrupt high fault currents, making it ideal for electrical distribution systems requiring robust protection. The reset actuator lever facilitates quick manual reset post trip, reducing downtime.

This MCCB complies with CE, IEC, and RoHS standards, underscoring its quality and adherence to environmental safety. Recognized as a Better World Product for sustainability, it is designed for ease of disassembly to support recycling and reduce environmental impact.

Common applications include industrial factories, manufacturing plants, HVAC systems, and commercial electrical panels. The breaker’s rated frequency of 50/60 Hz allows for use in diverse power systems. Country of origin: Italy.

Rated current of 100A suitable for medium power electrical distribution. Breaking capacity of 85 kA ensures robust short circuit protection. Fixed mounting type with front fixed terminals for secure installation. Thermal-magnetic tripping mechanism provides both overload and short circuit protection.

Compact dimensions of 150mm height, 105mm width, and 70mm depth for space-efficient design. Compliant with CE, IEC, and RoHS standards guaranteeing safety and environmental compliance. Rated AC voltage of 690V and DC voltage of 500V supports a wide range of electric systems.

Reset actuator lever enables easy manual reset after tripping events. Better World certified product designed for disassembly supporting sustainability. Explore more Molded Case Circuit Breakers and electrical protection solutions at EnvMart.
