Eaton PN1 Molded Case Circuit Breaker 1-Pole 125A 690V AC Thermal Magnetic Lever Reset 259142 PN1-125
Specifications
| Country of Origin | India |
|---|---|
| Brand | Eaton |
| Height | 155.2mm |
| Model | 259142 PN1-125 |
| Depth | 84.5mm |
| Width | 145mm |
| Current Rating | 125A |
| Series | PN1 |
| Terminal type | Screw |
| Breaking Capacity | 2.8kA |
| Number of Poles | 1 |
| Standards/Approvals | VDE, IEC, EN |
| Rated AC Voltage | 690V ac |
| Tripping Mechanism | Thermal Magnetic |
| Reset Actuator Type | Lever |
| Cooper Bussmann 8A Glass Cartridge Fuse, 6.3 x 32mmBrand | Cooper Bussmann |
| NZM7 3 pole circuit interruptor,125ABrand | Moeller |
Key Features
- Rated current of 125 amperes suitable for medium-load circuits.
- Breaking capacity of 2.8 kiloamperes ensures safe interruption of fault currents.
- Operates at rated AC voltage of 690 volts AC for high voltage systems.
- Equipped with a thermal magnetic tripping mechanism for precise response.
- Manual lever reset actuator for straightforward operation and maintenance.
- Screw terminal type ensures secure and reliable electrical connections.
- Meets international standards including VDE, IEC, and EN certifications.
- Designed as a main switch disconnector with manual switching capabilities.
Product Description
Eaton 259142 PN1-125 Molded Case Circuit Breaker is a high-quality, single-pole circuit protection device designed for industrial and commercial electrical distribution systems. It features a current rating of 125 amperes and a robust breaking capacity of 2.8 kA, suitable for interrupting fault currents safely in medium voltage AC systems rated up to 690 volts.
This breaker incorporates a thermal magnetic trip mechanism that provides reliable protection by combining thermal overload and magnetic short-circuit protection. The lever-type manual reset actuator enables easy operation and maintenance without requiring remote control functionality.
The compact form factor with dimensions of 155.2 mm height, 145 mm width, and 84.5 mm depth allows installation in tight panels while maintaining accessibility. Screw type terminals offer secure wiring connections for dependable electrical contact.
Standards compliance includes VDE, IEC, and EN approvals, reflecting adherence to rigorous electrical safety and performance requirements. The device is engineered to act as a main switch disconnector in electrical circuits.
Very suitable for applications in industrial manufacturing, automation systems, HVAC electrical panels, and robust power distribution networks requiring trustworthy circuit interruption and switching.
Provides 125A current rating. Breaking capacity of 2.8kA. Rated voltage: 690V AC. Thermal magnetic trip mechanism. Manual lever reset actuator. Compact dimensions: 155.2 x 145 x 84.5 mm. Screw terminal type. Complies with VDE, IEC, EN standards.
Explore more high-quality Eaton MCCB products and industrial circuit protection devices at EnvMart for comprehensive electrical safety solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has a current rating of 125 amperes, making it suitable for medium-load circuits.
The breaking capacity is 2.8 kiloamperes, ensuring safe interruption of fault currents.
It operates at a rated AC voltage of 690 volts, suitable for high voltage systems.
It incorporates a thermal magnetic tripping mechanism for precise response to overload and short-circuit conditions.
This unit features a manual lever reset actuator, allowing for straightforward operation and maintenance.
The dimensions are 155.2 mm in height, 145 mm in width, and 84.5 mm in depth, allowing for compact installation.
It uses screw type terminals, which ensure secure and reliable electrical connections.
It meets international standards including VDE, IEC, and EN certifications, reflecting its adherence to safety and performance requirements.
This circuit breaker is designed for use in industrial manufacturing, automation systems, HVAC electrical panels, and robust power distribution networks.
This model is a single-pole circuit breaker, designed for specific circuit protection needs.
The country of origin for this product is India.
This model belongs to the PN1 series, which includes various molded case circuit breakers by Eaton.
