SMC 10 mm Double Acting Cylinder CU Series Through Hole Mount Aluminium Alloy Body CU20-10D

SMC CU20-10D Double Acting Cylinder is a compact pneumatic piston rod cylinder designed to provide reliable motion control in a wide range of industrial and mechanical applications. Featuring a 10 mm stroke length and built with an aluminium alloy body, this cylinder combines strength with lightweight construction for enhanced performance.

The CU Series double acting design ensures precise and efficient actuation with both forward and return strokes powered pneumatically. Its through hole mount offers flexibility for installation, enabling it to fit into tight spaces and complex systems seamlessly. Rubber bumpers provide cushioning to minimize impact and noise, increasing equipment longevity and operator comfort.

This single rod cylinder employs a female piston rod with metric thread, facilitating easy integration into existing pneumatic setups. It is capable of handling a maximum piston speed of 500 mm/s and operates reliably up to 70°C, making it suitable for diverse HVAC, manufacturing, and automation environments.

Conforming to RoHS standards, the product assures compliance with environmental regulations. Manufactured in Japan, it meets rigorous quality control and durability benchmarks expected in industrial components.

Compact CU Series piston rod cylinder for efficient pneumatic actuation. Double acting for precise bidirectional motion control. Through hole mount for versatile and space-saving installation. Rubber bumper cushioning reduces noise and mechanical shock.

Aluminium alloy body provides durability with low weight. Female piston rod with metric threading for compatibility. Single rod design simplifies mounting and system integration. Maximum operating temperature of 70°C for broad use cases.

RoHS compliant ensuring environmentally safe materials. Japanese origin guarantees premium build quality.

This cylinder is widely applicable in industries requiring dependable pneumatic actuation, such as automation manufacturing, warehousing equipment, material handling systems, and fluid power tools. It is engineered to optimize machine efficiency, reduce maintenance costs, and maintain consistent performance in demanding industrial conditions.
